AJS Bobber 125 (2012-14)
The AJS Bobber 125 motorcycle was produced between 2012 and 2014. It is powered by a twin-cylinder, 4-stroke engine with a capacity of 124 cc and a maximum power output of 8 kW at 9500 rpm. The engine is cooled by liquid and has a 2-into-1 chrome exhaust and carburetor induction. It has an electric starting system and a 5-speed transmission with a wet, multi-plate clutch and chain final drive. The front suspension consists of telescopic forks, while the rear is a hard tail with a seat shock. The front and rear brakes are twin and single disc respectively. The wheels are multi-spoke alloy with an 80/90-21 front tire and 160/80-16 rear tire. The wheelbase measures 1670 mm and the seat height is 640 mm. The motorcycle has a dry weight of 161 kg and a GVWR of 275 kg. The fuel capacity is 8 liters and it is available in black.
Technical specifications:
Make Model: AJS Bobber 125
Year: 2012 – 14
Engine: Twin cylinder, 4-stroke
Capacity: 124 cc / 7.6 cub in
Bore x Stroke: 44 x 40 mm
Cooling System: Liquid cooled
Exhaust: 2-into-1, chrome
Induction: Carburetor
Ignition: Coil, CDI
Battery: 12V
Starting: Electric
Max Power: 8 kW / 11 hp @ 9500 rpm
Clutch: Wet, multi-plate
Transmission: 5-Speed
Final Drive: Chain
Front Suspension: Telescopic forks, USD
Rear Suspension: Hard tail, seat shock
Front Brakes: Twin disc
Rear Brakes: Single disc
Wheels: Multi spoke, alloy
Front Tyre: 80/90-21
Rear Tyre: 160/80-16
Wheelbase: 1670 mm / 65.7 in.
Seat Height: 640 mm / 25 in
Dry Weight: 161 kg / 355 lbs
GVWR: 275 kg / 606 lbs
Fuel Capacity: 8 L / 2.1 US gal
Colours: Black
