The MZ 1000ST was a motorcycle model produced by MZ in 2006. It had a four-stroke, parallel twin-cylinder, DOHC engine with a capacity of 996 cc. The bike had a liquid cooling system and an electronic fuel injection induction. Its maximum power was 117 horsepower at 8000 rpm, and its maximum torque was 98 Nm at 7000 rpm. The motorcycle had a six-speed transmission, a chain final drive, and a dual-tube bridge frame. The front suspension featured a Marzocchi upside-down fork, while the rear suspension had a Sachs Monoshock. The bike’s front brakes were 2x320mm discs with 4 piston calipers, and the rear brakes were a single 240mm disc with 2 piston calipers. The front and rear tyre sizes were 120/70-17 and 180/55-17 respectively. The bike’s rake was 24.5 degrees, its trail was 98mm, and its wheelbase was 1445mm. The seat height was 820mm, and the dry weight was 210kg. The fuel capacity was 20 litres, or 5.2 US gallons.
Technical specifications:
Make Model: MZ 1000ST
| Year | 2006 |
|---|---|
| Engine | Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder |
| Capacity | 996 cc / 60.9 cu-in |
| Bore x Stroke | 96 X 69 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 12.5:1 |
| Exhaust | Euro 2 / 2 Catalytic converter |
| Induction | Electronic Fuel Injection |
| Ignition | Electric CDI |
| Starting | Electric |
| Max Power | 117 hp / 83.8 kW @ 8000 rpm |
| Max Torque | 98 Nm / 71 lb-ft @ 7000 rpm |
| Clutch | Wet multi-plate hydraulic |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Frame | Dual tube bridge frame |
| Front Suspension | Marzocchi Upside-down fork |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Suspension | Sachs Monoshock |
| Rear Wheel Travel | 120 mm / 4.7 in |
| Front Brakes | 2x 320mm discs 4 piston calipers |
| Rear Brakes | Single 240mm disc 2 piston caliper |
| Front Tyre | 120/70-17 |
| Rear Tyre | 180/55-17 |
| Rake | 24.5 degrees |
| Trail | 98 mm / 3.9 in |
| Wheelbase | 1445 mm / 56.9 in |
| Seat Height | 820 mm / 32.3 lbs |
| Dry Weight | 210 kg / 463.0 lbs |
| Fuel Capacity | 20 Litres / 5.2 US gal |
