MZ 1000ST (2006)

The MZ 1000ST was a motorcycle model produced by MZ in 2006. It had a four-stroke, parallel twin-cylinder, DOHC engine with a capacity of 996 cc. The bike had a liquid cooling system and an electronic fuel injection induction. Its maximum power was 117 horsepower at 8000 rpm, and its maximum torque was 98 Nm at 7000 rpm. The motorcycle had a six-speed transmission, a chain final drive, and a dual-tube bridge frame. The front suspension featured a Marzocchi upside-down fork, while the rear suspension had a Sachs Monoshock. The bike’s front brakes were 2x320mm discs with 4 piston calipers, and the rear brakes were a single 240mm disc with 2 piston calipers. The front and rear tyre sizes were 120/70-17 and 180/55-17 respectively. The bike’s rake was 24.5 degrees, its trail was 98mm, and its wheelbase was 1445mm. The seat height was 820mm, and the dry weight was 210kg. The fuel capacity was 20 litres, or 5.2 US gallons.

Technical specifications:

Make Model: MZ 1000ST

Year: 2006

Engine: Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder
Capacity: 996 cc / 60.9 cu-in
Bore x Stroke: 96 X 69 mm
Cooling System: Liquid cooled
Compression Ratio: 12.5:1
Exhaust: Euro 2 / 2 Catalytic converter
Induction: Electronic Fuel Injection
Ignition: Electric CDI
Starting: Electric
Max Power: 117 hp / 83.8 kW @ 8000 rpm
Max Torque: 98 Nm / 71 lb-ft @ 7000 rpm
Clutch: Wet multi-plate hydraulic
Transmission: 6 Speed
Final Drive: Chain
Frame: Dual tube bridge frame

Front Suspension: Marzocchi Upside-down fork
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Sachs Monoshock
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: 2x 320mm discs 4 piston calipers
Rear Brakes: Single 240mm disc 2 piston caliper
Front Tyre: 120/70-17
Rear Tyre: 180/55-17
Rake: 24.5 degrees
Trail: 98 mm / 3.9 in
Wheelbase: 1445 mm / 56.9 in
Seat Height: 820 mm / 32.3 lbs
Dry Weight: 210 kg / 463.0 lbs
Fuel Capacity: 20 Litres / 5.2 US gal
