The MZ 1000S is a motorcycle that was produced from 2004 to 2007. It has a four-stroke, parallel twin-cylinder engine with a capacity of 996cc and a bore x stroke of 96 x 69mm. It is liquid-cooled and has a compression ratio of 12.5:1. The bike has electronic fuel injection and an electric CDI ignition. It can produce a max power of 117 hp and a max torque of 98 Nm. The clutch is wet multi-plate hydraulic and it has a six-speed transmission. The MZ 1000S has a dual-tube bridge frame, Marzocchi upside-down fork front suspension with 120mm of travel, and a Sachs Monoshock rear suspension also with 120mm of travel. The front brakes are two 320mm discs with four-piston calipers and the rear brake is a single 240mm disc with a two-piston caliper. The bike has a wheelbase of 1445mm, a seat height of 820mm, and a dry weight of 210.0kg. It has a fuel capacity of 20 litres and can reach a top speed of 146.8mph. The standing quarter-mile time is 10.9 seconds with a speed of 119.5mph.
Technical specifications:
Make Model: MZ 1000S
| Year | 2004 – 07 |
|---|---|
| Engine | Four stroke, parallel twin cylinder, DOHC, 4 valve per cylinder |
| Capacity | 996 cc / 60.9 cu-in |
| Bore x Stroke | 96 X 69 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 12.5:1 |
| Exhaust | Euro 2 / 2 Catalytic converter |
| Induction | Electronic Fuel Injection |
| Ignition | Electric CDI |
| Starting | Electric |
| Max Power | 117 hp / 83.8 kW @ 8000 rpm |
| Max Torque | 98 Nm / 71 lb-ft @ 7000 rpm |
| Clutch | Wet multi-plate hydraulic |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Frame | Dual tube bridge frame |
| Front Suspension | Marzocchi Upside-down fork |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Suspension | Sachs Monoshock |
| Rear Wheel Travel | 120 mm / 4.7 in |
| Front Brakes | 2x 320mm discs 4 piston calipers |
| Rear Brakes | Single 240mm disc 2 piston caliper |
| Front Tyre | 120/70-17 |
| Rear Tyre | 180/55-17 |
| Rake | 24.5 degrees |
| Trail | 98 mm / 3.9 in |
| Wheelbase | 1445 mm / 56.9 in |
| Seat Height | 820 mm / 32.3 lbs |
| Dry Weight | 210.0 kg / 463.0 lbs |
| Fuel Capacity | 20 Litres / 5.2 US gal |
| Standing 1/4 Mile | 10.9 sec / 119.5 mph |
| Top Speed | 146.8 mph |
