The Indian Dark Horse motorcycle was produced from 2010-11 with a four-stroke, V-twin engine with a capacity of 1720cc/105 cu-in. It has a compression ratio of 9.0:1, closed-loop sequential port fuel injection, and digital CDI ignition. The motorcycle has a 5-speed transmission, a final drive belt and a maximum torque of 100 lb-ft/ 135.5 Nm. The frame is made of high tensile steel with a monoshock suspension system. The front suspension has 41mm diameter and 108mm wheel travel, while the rear suspension is a single shock with 73mm wheel travel. The motorcycle has single 292mm disc front brakes with 2 piston calipers and a single 292mm disc rear brake with 1 piston caliper. The front and rear tyres are sized at 130/90-16 and 150/90-16. The dimensions of the bike are L 2552.7mm/100.5in, W 1028.7mm/40.5in, and H 1282.7mm/50.5in. The wheelbase is 1737.3mm/68.4in and the seat height is 692mm/27.2in. The dry weight of the motorcycle is 339kg/748lb, and it has a fuel capacity of 20.8 liters/5.5 gal.
Technical specifications:
Make Model: Indian Dark Horse
| Year | 2010 – 11 |
|---|---|
| Engine | Four stroke, V-twin, 2 valve per cylinder. |
| Capacity | 1720 cc / 105 cu-in |
| Bore x Stroke | 3.966 x 4.25 in. |
| Cooling System | Air cooled |
| Compression Ratio | 9.0:1 |
| Induction | Closed loop sequential port fuel injection |
| Ignition | Digital CDI |
| Starting | -Electric |
| Max Toque | 100 lb-ft / 135.5 Nm |
| Transmission | 5 Speed |
| Final Drive | Belt |
| Gear Ratio | 1st 10.441:1 2nd 7.090:1 3rd 5.172:1 4th 3.984:1 5th 3.193:1 6th 2.771:1 |
| Frame | High tensile steel, monoshock |
| Front Suspension | 41 mm diameter; 108 mm wheel travel |
| Rear Suspension | Single shock, 73mm wheel travel. |
| Front Brakes | Single 292mm disc 2 piston calipers |
| Rear Brakes | Single 292mm disc 1 piston calipers |
| Front Tyre | 130/90-16 |
| Rear Tyre | 150/90-16 |
| Rake | 34 degrees |
| Trail | 150 mm / 5.9 in |
| Dimensions | Length 2552.7 mm / 100.5 in Width 1028.7 mm / 40.5 in Height 1282.7 mm / 50.5 in |
| Wheelbase | 1737.3 mm / 68.4 in |
| Seat Height | 692 mm / 27.2 in |
| Seat Height | 680.8 mm / 27.2 in |
| Dry Weight | 339 kb / 748 lb |
| Fuel Capacity | 20.8 Litres / 5.5 Gal |
