MV Agusta F4 1000 Senna (2006)

Entry updated

MV Agusta F4 1000 Senna (2006)

At a glance

Capacity
998 cc / 60.9 cu-in
Power
128.8 kW / 172.8 hp @ 11750 rpm
Torque
113 Nm / 11.5 kgf-m @ 9000 rpm

The full picture.

The MV Agusta F4 1000 Senna is a 2006 motorcycle with a four-stroke transverse four-cylinder engine with a 998cc capacity and a 13.0:1 compression ratio. It has Weber Marelli 1,6 M ignition-injection integrated system induction, with multipoint electronic injection ignition and electric starting. The motorcycle produces a maximum power of 172.8 horsepower at 11750 rpm and a maximum torque of 113 Nm at 9000 rpm. The clutch is wet, multiple discs, cable operated, and the transmission has six speeds with a final drive of a chain. The front suspension is an inverted upside-down telescopic hydraulic fork with rebound-compression damping and a spring preload adjustment with a titanium nitride anti-friction treatment. The rear suspension is progressive, single shock absorber with rebound and compression high-speed/low-speed damping and spring preload hydraulic control. The front brakes consist of 2x 310mm discs and six-piston calipers, and the rear brakes have a single 210mm disc and four-piston caliper. The motorcycle has a 120/65 ZR17 front tire and a 180/55 ZR17 rear tire. It weighs 190 kg and has a fuel capacity of 21 liters.


Technical specifications:

Make Model: MV Agusta F4 1000 Senna

Motorcycle technical specifications
Year2006
EngineFour stroke, transverse four cylinder. DOHC, 4 valves per cylinder
Capacity998 cc / 60.9 cu-in
Bore x Stroke76 x 55 mm
Cooling SystemLiquid cooled
Compression Ratio13.0:1
InductionWeber Marelli 1,6 M ignition – injection integrated system
IgnitionMultipoint electronic injection
StartingElectric
Max Power128.8 kW / 172.8 hp @ 11750 rpm
Max Torque113 Nm / 11.5 kgf-m @ 9000 rpm
ClutchWet, multiple discs, cable operated
Transmission6 Speed
Final DriveChain
Front SuspensionInverted upside down telescopic hydraulic fork with rebound-compression damping and spring preload adjustment, Titanium Nitride anti-friction treatment
Rear SuspensionProgressive, single shock absorber with rebound and compression High speed / Low speed damping and spring preload hydraulic control
Front Brakes2x 310mm discs 6 piston calipers
Rear BrakesSingle 210mm disc 4 piston caliper
Front Tyre120/65 ZR17
Rear Tyre180/55 ZR17
DimensionsLength 2007 mm / 79.0 in Width 685 mm / 26.9 in
Wheelbase1408 mm / 55.4 in
Dry Weight190 kg / 418.8 lbs
Fuel Capacity21 Litres / 5.5 US gal
