The MV Agusta Brutal 910S is a motorcycle model produced in 2005 and 2006. It features a four-stroke transverse four-cylinder engine with a capacity of 908cc and a cooling system with separated liquid and oil radiators. The engine has a compression ratio of 13.0:1 and is equipped with a Weber Marelli 1.6 M ignition injection integrated system. The bike has a multipoint electronic injection starting system with a maximum power of 139 hp at 12500 RPM and a maximum torque of 96 Nm at 10500 RPM. The motorcycle has a six-speed wet clutch transmission with a chain final drive and a primary drive of 50/79. The bike has a steel tubular frame and 50mm Marzocchi upside-down telescopic hydraulic forks. The front brakes have two 310mm discs and 6 piston calipers, while the rear brake has one 210mm disc and a 4 piston caliper. The front and rear tire sizes are 120/65-17 and 190/50-17, respectively, and the motorcycle has a ground clearance of 135mm. The bike has a dry weight of 185kg, a fuel capacity of 19 liters, and can reach a top speed of 241.4 km/h. The bike has a length of 2020mm, a width of 760mm, and a height of 805mm with a wheelbase of 1410mm and a seat height of 805mm. The bike can reach a standing 1/4 mile time of 11.2 seconds.
Technical specifications:
Make Model: MV Agusta Brutal 910S
| Year | 2005 – 06 |
|---|---|
| Engine | Four stroke, transverse four cylinder. DOHC, 4 valves per cylinder. |
| Capacity | 908 cc / 55.4 cu-in |
| Bore x Stroke | 76 x 50.1 mm |
| Cooling System | Cooling with separated liquid and oil radiators |
| Compression Ratio | 13.0;1 |
| Induction | Weber Marelli 1.6 M ignition injection integrated system |
| Ignition | Multipoint electronic injection |
| Starting | Electric |
| Max Power | 139 hp / 102.2 kW @ 12500 rpm |
| Max Torque | 96 Nm / 70.8 lb-ft @ 10500 rpm |
| Clutch | Wet, multi – disc |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Primary Drive | 50/79 |
| Gear Ratio | 1st Speed 13/38 105,5 Km/h (65.5 mph) at 12000 rpm 2nd Speed 16/34 145,1 Km/h (90.1 mph) at 12000 rpm 3rd Speed 18/32 173,4 Km/h (107.7 mph) at 12000 rpm 4th Speed 20/30 205,5 Km/h (127.6 mph) at 12000 rpm 5th Speed 22/29 233,9 Km/h (145.2 mph) at 12000 rpm 6th Speed 19/23 262,0 Km/h (162.7 mph) at 12000 rpm |
| Frame | Cromo Steel tubular |
| Front Suspension | 50mm Marzocchi Upside down telescopic hydraulic forks, preload compression damping and spring reload adjustment |
| Front Wheel Travel | 126 mm / 4.9 in |
| Rear Suspension | Progressive single shock, |
| Rear Wheel Travel | 120mm / 4.7 in |
| Front Brakes | 2x 310mm discs 6 piston calipers |
| Rear Brakes | Single 210mm disc 4 piston caliper |
| Front Tyre | 120/65-17 |
| Rear Tyre | 190/50 -17 |
| Trail | 101,5 mm / 4.0 in |
| Dimensions | Length 2020 mm / 79.5 in Width 760 mm / 29.94 in Height 805 mm / 31.72 in |
| Wheelbase | 1410 mm / 55.55 in |
| Seat Height | 805 mm / 31.7 in |
| Ground Clearance | 135 mm / 5.3 in |
| Dry Weight | 185 kg / 407.9 lbs |
| Fuel Capacity | 19 Litres / 5.0 US gal |
| Standing 1/4 Mile | 11.2 sec |
| Top Speed | 241.4 km/h |
