The 2012 Moto Morini Rebello 1200 Giubileo motorcycle features a four-stroke 87 degrees V longitudinal twin engine with a capacity of 1187 cc/72.5 cu-in, and a liquid cooling system. Its maximum power is 86 kW/117 hp at 8500 rpm, and its maximum torque is 102 Nm/10.4 kgf-m at 6750 rpm. The bike has a multiplate clutch in oil bath with antis kipping and radial master cylinder, a six-speed transmission, and a chain final drive. It also has a Verlicchi high strength steel tubular trellis frame and front suspension with a Marzocchi upside-down fork with 50mm stems and a 152mm wheel travel. The rear suspension is a progressive linkage with Sachs adjustable rebound, compression spring loading, and a 150mm wheel travel. The front brakes are dual 320mm discs with four-piston calipers, and the rear brakes are a single 220mm disc with a two-piston caliper. The motorcycle’s front tire size is 120/70 ZR 17, and its rear tire size is 180/55 ZR 17. Its seat height and fuel capacity are not specified.
Technical specifications:
Make Model: Moto Morini Rebello 1200 Giubileo
| Year | 2012 |
|---|---|
| Engine | Four stroke, 87 degrees V longitudinal twin, DOHC, 4 valves per cylinder |
| Capacity | 1187 cc / 72.5 cu-in |
| Bore x Stroke | 107 x 66 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 12.5:1 |
| Lubrication | Forced with trochoidal pump |
| Induction | Magneti Marelli fuel injection 54 mm throttle body |
| Ignition | I.A.W. electronic |
| Starting | Electric |
| Max Power | 86 kW / 117 hp @ 8500 rpm |
| Max Torque | 102 Nm / 10.4 kgf-m @ 6750 rpm |
| Clutch | Multiplate clutch in oil bath with antis kipping and radial master cylinder. |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Frame | Verlicchi high strength steel tubular trellis frame |
| Front Suspension | Marzocchi upside down with 50mm stems, 152mm wheel travel. |
| Rear Suspension | Progressive linkage wit Sachs Adjustable in rebound, compression spring loading, 150mm wheel travel |
| Front Brakes | 2x 320mm discs 4 piston callipers |
| Rear Brakes | Single 220mm disc 2 piston caliper |
| Front Tyre | 120/70 ZR 17 |
| Rear Tyre | 180/55 ZR 17 |
| Seat Height | |
| Dry Weight | |
| Fuel Capacity |
