The Moto Morini Granpasso 1200 is a motorcycle produced between 2014-15. It features a four-stroke, 1187cc engine with liquid cooling, a silencer with a 3-way catalytic converter, and Magneti Marelli fuel injection. It has a maximum power of 86kW/117hp at 8500 RPM and maximum torque of 102 Nm/10.4 kgf-m at 6750 RPM. The motorcycle has a multiplate clutch in oil bath with anti-skipping and a six-speed transmission with chain final drive. It has a Verlicchi high-strength steel tubular trellis frame and Marzocchi upside-down suspension in the front and an Ohlins single shock rear suspension with separate tank, preload, rebound, and compression adjustable. The front brakes consist of two 298mm discs and 2 piston calipers while the rear brake has a single 255mm disc and 2 piston calipers. The motorcycle has a height of 875mm, length of 2170mm, and width of 850mm with a wheelbase of 1505mm, ground clearance of 200mm, and seat height of 875mm. It has a dry weight of 210kg and a fuel capacity of 27 liters, with a reserve of 5.5 liters.
Technical specifications:
Make Model: Moto Morini Granpasso 1200
| Year | 2014 – 15 |
|---|---|
| Engine | Four stroke, 87 degreesV longitudinal twin, DOHC, 4 valves per cylinder |
| Capacity | 1187 cc / 72.4 cu-in |
| Bore x Stroke | 107 x 66 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 12.5:1 |
| Exhaust | Silencer, 3-way catalytic converter with oxygen sensor |
| Induction | Magneti Marelli fuel injection 54 mm throttle body |
| Ignition | I.A.W electronic |
| Starting | Electric |
| Max Power | 86 kW / 117 hp @ 8500 rpm |
| Max Torque | 102 Nm / 10.4 kgf-m @ 6750 rpm |
| Clutch | Multiplate clutch in oil bath with antis kipping and radial master cylinder. |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Gear Ratio | 1st 13/36 / 2nd 17/32 / 3rd 20/30 / 4th 22/28 / 5th 23/26 / 6th 24/25 |
| Frame | Verlicchi high strength steel tubular trellis frame |
| Front Suspension | Marzocchi upside down with 50mm stems |
| Front Wheel Travel | 190 mm / 7.5 in |
| Rear Suspension | ~Ahlins single shock, with separate tank, preload , rebound and compression adjustable |
| Rear Wheel Travel | 200 mm / 7.9 in |
| Front Brakes | 2x 298mm discs 2 piston callipers |
| Rear Brakes | Single 255mm disc 2 piston caliper |
| Front Tyre | 110/80 ZR 19 |
| Rear Tyre | 180/55 ZR 17 |
| Rake | 26.5 degrees |
| Trail | 110 mm / 4.3 in |
| Dimensions | Height 875 mm / 34.4 in length 2170 mm / 85.4 in Width 850 mm / 33.5 in |
| Wheelbase | 1505 mm / 59.3 in |
| Ground Clearance | 200 mm / 7.9 in |
| Seat Height | 875 mm / 34,4 in |
| Dry Weight | 210 Kg / 463 lbs |
| Fuel Capacity | 27 Litres / 7,1 US gal |
| Reserve | 5.50 litres / 1.45 gal |
