The Moto Morini 9½ is a four-stroke motorcycle that was made between 2008 and 2012. It has a 1187cc engine, with a bore of 107mm and a stroke of 66mm, and can reach a compression ratio of 11.8:1. The bike uses a forced lubrication system and Magneti Marelli indirect electronic injection with a 54mm throttle body. The ignition is I.A.W. electronic and the bike starts with an electric starter. The maximum power output of the bike is 88 kW or 120 hp at 8,500 rpm, while the maximum torque is 105 Nm or 10.4 kgf-m at 6,750 rpm. The transmission has six gears and the final drive is via a chain. The bike features ALS450 steel tubular trellis with varying diameters, with 50mm Marzocchi front forks, and a single lateral fork with adjustable spring preloading at the rear. The front and rear brakes use 320mm discs with four-piston calipers and a single 220mm disc with two-piston caliper respectively. The wheels use 120/70 ZR17 and 180/55 ZR17 tyres at the front and rear respectively. The bike has a rake of 34.0 degrees and is 2170mm in length, 166mm ground clearance, and 198.0kg in dry weight, with a fuel capacity of 21 litres.
Technical specifications:
Make Model: Moto Morini 91/2
| Year | 2008 – 12 |
|---|---|
| Engine | Four stroke, 87 degrees V longitudinal twin, DOHC, 4 valves per cylinder |
| Capacity | 1187 cc / 72.5 cu-in |
| Bore x Stroke | 107 x 66 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 11.8;1 |
| Lubrication | Forced with trochoidal pump |
| Induction | Magneti Marelli indirect electronic injection with 54 mm throttle body |
| Ignition | I.A.W. electronic |
| Starting | Electric |
| Max Power | 88 kW / 120 hp @ 8500 rpm |
| Max Torque | 105 Nm / 10.4 kgf-m @ 6750 rpm |
| Clutch | Wet, multi-plate, anti-hopping system |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Frame | ALS450 steel tubular trellis with varying diameters |
| Front Suspension | 50mm Marzocchi – upside down forks, 150mm wheel travel |
| Front Wheel Travel | 130 mm / 5.1 in |
| Rear Suspension | Single lateral fork with piggy back tank and adjustable spring preloading |
| Rear Wheel Travel | 130 mm / 5.1 in |
| Front Brakes | 2x 320mm discs 4 piston calipers |
| Rear Brakes | Single 220mm disc 2 piston caliper |
| Front Tyre | 120/70 ZR17 |
| Rear Tyre | 180/55 ZR17 |
| Rake | 34.0 degrees |
| Length | 2170 mm / 85.4 in |
| Ground Clearance | 166 mm / 6.5 in |
| Dry Weight | 198.0 kg / 436.5 lbs |
| Fuel Capacity | 21 Litres / 5.5 US gal |
