The Gilera Giubileo 125 & 175 motorcycle was manufactured from 1964 to 1969. The bike had a four-stroke, single-cylinder engine with a capacity of 175cc. The cooling system was air-cooled, and the bike had a compression ratio of. The ignition was 6 volts and it had a carburetor for its induction. The maximum power the bike produced was 7.2 kW / 10 hp at 7000 rpm. It had a 4-speed transmission and a chain final drive. The frame was a single cradle, and the front suspension had hydraulic telescopic forks, while the rear shock absorbers were dual. The front and rear brakes were drums and the front tyre was 2.75-17, while the rear tyre was 3.00-17. The dry weight of the bike was 114 kg and the fuel capacity was 15 litres.
Technical specifications:
Make Model: Gilera Giubileo 125 & 175
| Year | 1964 – 69 |
|---|---|
| Engine | Four stroke, single cylinder, 2 valves |
| Capacity | 175 cc |
| Bore x Stroke | 60 x 61 mm |
| Cooling System | Air Cooled |
| Compression Ratio | |
| Induction | Carburetor |
| Ignition | 6 Volt |
| Starting | Kick |
| Max Power | 7.2 kW / 10 hp @ 7000 rpm |
| Transmission | 4 Speed |
| Final Drive | Chain |
| Frame | Single cradle |
| Front Suspension | Hydraulic telescopic forks |
| Rear Suspension | Dual chocks |
| Front Brakes | Drum |
| Rear Brakes | Drum |
| Front Tyre | 2.75 -17 |
| Rear Tyre | 3.00 -17 |
| Dry Weight | 114 kg |
| Fuel Capacity | 15 Litres |
