The CF Moto 150 Charm AutoMatic is a motorcycle with a four-stroke, single-cylinder, SOHC, two-valve engine and a capacity of 154cc. The compression ratio is 10.5:1 and it has a liquid-cooled cooling system. The bike is equipped with an automatic lubrication system and a carburetor for induction. The CDI ignition is electric and the bike is capable of generating a maximum power output of 10.8hp at 7500rpm and a maximum torque of 10.7Nm at 6500rpm. The bike uses a wet multi-plate clutch and has a shaft final drive. The front suspension is equipped with a hydraulic telescopic fork while the rear suspension is dual shock. The motorcycle has a single disc brake for both the front and rear wheels. The front tire size is 100/80-16 while the rear tire is 110/80-16. The bike has a wheelbase of 1384mm and a seat height of 813mm. The ground clearance of the bike is 160mm and it has a dry weight of 126kg. The fuel capacity of the bike is 8 liters or 2.1 US gallons.
Technical specifications:
Make Model: CF Moto 150 Charm AutoMatic
| Year | 2009 – |
|---|---|
| Engine | Four stroke, Single cylinder, SOHC, 2 valve. |
| Capacity | 154 cc / 9.4 cu-in |
| Bore x Stroke | 57.0 x 58.6 mm |
| Compression Ratio | 10.5:1 |
| Cooling System | Liquid cooled |
| Lubrication | Automatic |
| Induction | Carburetor |
| Ignition | CDI |
| Starting | Electric |
| Max Power | 10.8 hp / 8.8 kW @ 7500 rpm |
| Max Torque | 10.7 Nm / 6.8 lb-ft @ 6500rpm |
| Clutch | Wet multi-plate |
| Transmission | Automatic |
| Final Drive | Shaft |
| Front Suspension | Hydraulic telescopic fork |
| Rear Suspension | Dual Shock |
| Front Brakes | Single disc |
| Rear Brakes | Single disc |
| Front Tyre | 100/80-16 |
| Rear Tyre | 110/80-16 |
| Wheelbase | 1384 mm / 54.5 in |
| Seat Height | 813 mm / 32 in |
| Ground Clearance | 160 mm 6.3 in |
| Dry Weight | 126 kg / 277.8 lbs |
| Fuel Capacity | 8 Litres / 2.1 US gal |
