CF Moto 150 Charm AutoMatic (2009)

The CF Moto 150 Charm AutoMatic is a motorcycle with a four-stroke, single-cylinder, SOHC, two-valve engine and a capacity of 154cc. The compression ratio is 10.5:1 and it has a liquid-cooled cooling system. The bike is equipped with an automatic lubrication system and a carburetor for induction. The CDI ignition is electric and the bike is capable of generating a maximum power output of 10.8hp at 7500rpm and a maximum torque of 10.7Nm at 6500rpm. The bike uses a wet multi-plate clutch and has a shaft final drive. The front suspension is equipped with a hydraulic telescopic fork while the rear suspension is dual shock. The motorcycle has a single disc brake for both the front and rear wheels. The front tire size is 100/80-16 while the rear tire is 110/80-16. The bike has a wheelbase of 1384mm and a seat height of 813mm. The ground clearance of the bike is 160mm and it has a dry weight of 126kg. The fuel capacity of the bike is 8 liters or 2.1 US gallons.

Technical specifications:

Make Model: CF Moto 150 Charm AutoMatic

Year: 2009 –

Engine: Four stroke, Single cylinder, SOHC, 2 valve.
Capacity: 154 cc / 9.4 cu-in
Bore x Stroke: 57.0 x 58.6 mm
Compression Ratio: 10.5:1
Cooling System: Liquid cooled
Lubrication: Automatic
Induction: Carburetor
Ignition: CDI
Starting: Electric
Max Power: 10.8 hp / 8.8 kW @ 7500 rpm
Max Torque: 10.7 Nm / 6.8 lb-ft @ 6500rpm
Clutch: Wet multi-plate
Transmission: Automatic
Final Drive: Shaft
Front Suspension: Hydraulic telescopic fork

Rear Suspension: Dual Shock
Front Brakes: Single disc
Rear Brakes: Single disc
Front Tyre: 100/80-16
Rear Tyre: 110/80-16
Wheelbase: 1384 mm / 54.5 in
Seat Height: 813 mm / 32 in
Ground Clearance: 160 mm 6.3 in
Dry Weight: 126 kg / 277.8 lbs
Fuel Capacity: 8 Litres / 2.1 US gal
