The Bajaj XCD 125 DTS-Si motorcycle was produced from 2008 to 2010. It has a four-stroke, single cylinder, SOHC, 2 valve engine with a capacity of 124.5 cc. The compression system is 9.5:1 and it is air/oil cooled with a wet sump, forced lubrication system. The bike has a side draft carburetor with a UCSL Mikuni VM16 and microprocessor controlled digital CDI ignition. The battery is 12 volts and 5 amps and it has both electric and kick start. The bike has a wet, multiplate clutch and a 4-speed, constant mesh transmission with a chain final drive. The frame is a single down tube with the engine as the stress member. The bike has a length of 1980mm, width of 760mm, and height of 1200mm with a wheelbase of 1275mm and ground clearance of 170mm. The front suspension is telescopic forks with 125mm wheel travel and the rear suspension is trailing arm with dual SNS type springs with hydraulic shock absorbers, adjustable with 105mm wheel travel. The bike has drum brakes with the front brakes being 130mm and rear brakes being 130mm. It has aluminium alloy, 6-spoke wheels with a 2.75-17 front wheel and a 3.00-17 rear wheel. The bike weighs 112kg and has a fuel capacity of 8L with a fuel reserve of 1.8L, and can go up to 90km/h. The available colors were black, red, silver, and blue. A review of the bike was published in BS Motoring.
Technical specifications:
Make Model: Bajaj XCD 125 DTS-Si
| Year | 2008 – 10 |
|---|---|
| Engine | Four stroke, single cylinder, SOHC, 2 valve |
| Capacity | 124.5 cc / 7.6 cu in |
| Bore x Stroke | 54 x 54.4 mm |
| Compression System | 9.5:1 |
| Cooling System | Air/oil cooled |
| Lubrication System | Wet sump, forced |
| Exhaust | Exhaust-TEC |
| Induction | Carburetor, side draught, UCSL Mikuni VM16 |
| Ignition | Microprocessor controlled Digital CDI |
| Battery | 12V, 5Ah |
| Starting | Electric & Kick start |
| Max Power | 7.0 kW / 9.4 hp @ 7000 rpm |
| Max Torque | 10.8 Nm / 1.1 kgf-m / 8.0 ft. lbs @ 6500 rpm |
| Clutch | Wet, multiplate |
| Transmission | 4 Speed, constant mesh |
| Final Drive | Chain |
| Frame | Single down tube with engine as stress member |
| Dimensions | Length: 1980 mm / 78.0 in Width: 760 mm / 29.9 in Height: 1200 mm / 47.2 in |
| Wheelbase | 1275 mm / 50.2 in |
| Ground Clearance | 170 mm / 6.7 in |
| Front Suspension | Telescopic forks |
| Front Wheel Travel | 125 mm / 4.9 in |
| Rear Suspension | Trailing arm with dual SNS type springs with hydraulic shock absorbers, adjustable |
| Rear Wheel Travel | 105 mm / 4.1 in |
| Front Brakes | 130 mm drum |
| Rear Brakes | 130 mm drum |
| Wheels | Aluminium alloy, 6-spoke |
| Front Wheel | 2.75-17 |
| Rear Wheel | 3.00-17 |
| Dry Weight | 112 kg / 247 lbs |
| Fuel Capacity | 8 L / 2.1 US gal |
| Fuel Reserve | 1.8 L / 0.48 US gal |
| Top Speed | 90 km/h / 56 mph |
| Colours | Black, Red, Silver, Blue |
| Review | BS Motoring |
