The Victory Cross Country motorcycle was produced from 2010-11 and has a four stroke, 50 degree V twin SOHC engine with self-adjusting cam chains and hydraulic lifters. Its capacity is 1731cc /106 cu-in with a bore x stroke of 101 x 108 mm, and it is air/oil cooled with a compression ratio of 9.8:1. The bike features split dual exhaust with crossover, electronic fuel injection with 45mm throttle bodies, and an electric starting system. Its maximum power is 96.9 hp / 71.3 kW and maximum torque is 153 Nm / 15.6 kg-m. The clutch is wet, multi-plate and it has a 6-speed transmission with a carbon fiber reinforced belt for the final drive. The front suspension includes a 43mm conventional telescopic fork with front wheel travel of 130 mm / 5.1 in, while the rear suspension is a single, mono-tube gas forged and cast aluminum with rising-rate linkage and preload adjustable spring. The rear wheel travel is 120 mm / 4.7 in. Front brakes are 2x 300mm floating rotors with 3 piston calipers, while the rear brake is a single 300mm floating rotor with a 2 piston caliper. The front tyre is 130/70 R18 and the rear tyre is 180/60 R16. The seat height is 667 mm / 26.25 in, the GVWR is 618 kg / 1360 lbs, and the dry weight is 347 kg / 765 lbs. The bike has a fuel capacity of 22.7 Litres / 5.8 US gal.
Technical specifications:
Make Model: Victory Cross Country
| Year | 2010 – 11 |
|---|---|
| Engine | Four stroke, 50 degrees V twin SOHC, 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters |
| Capacity | 1731cc /106 cu-in |
| Bore x Stroke | 101 x 108 mm |
| Cooling System | Air/oil cooled |
| Compression Ratio | 9.8:1 |
| Exhaust | Split dual exhaust with crossover |
| Induction | Electronic Fuel Injection with 45mm throttle bodies |
| Starting | -Electric |
| Max Power | 96.9 hp / 71.3 kW |
| Max Torque | 153 Nm / 15.6 kg-m |
| Clutch | Wet, multi-plate |
| Transmission | 6 Speed |
| Final Drive | Carbon fiber reinforced belt |
| Front Suspension | 43mm Conventional telescopic fork |
| Front Wheel Travel | 130 mm / 5.1 in |
| Rear Suspension | Single, mono-tube gas forged and cast aluminum w/ rising-rate linkagel, preload adjustable spring |
| Rear Wheel Travel | 120 mm / 4.7 in |
| Front Brakes | 2x 300mm floating rotor 3 piston caliper |
| Rear Brakes | Single 300mm floating rotor 2 piston caliper |
| Front Tyre | 130/70 R18 |
| Rear Tyre | 180/60 R16 |
| Seat Height | 667 mm / 26.25 in |
| GVWR | 618 kg / 1360 lbs |
| Dry Weight | 347 kg / 765 lbs |
| Fuel Capacity | 22.7 Litres / 5.8 US gal |
