Triumph Tiger Explorer XC (2013)

The 2013 Triumph Tiger Explorer XC is a motorcycle with a four stroke, transverse three-cylinder engine that has a capacity of 1215 cc. With a liquid-cooled cooling system, the motorcycle has a compression ratio of 12.0:1 and a multipoint sequential electronic fuel injection with SAI induction. The maximum power of the bike is 101 kW / 135 hp @ 9300rpm, while its maximum torque is 121 Nm / 21.6 kgf-m / 89 ft-lbs @ 6400 rpm. The bike has a wet, multi-plate clutch and a 6-speed transmission. It also has a tubular steel trellis frame and a single-sided cast aluminum alloy with shaft drive swingarm. The front suspension is Kayaba 46mm upside-down forks, while the rear suspension is Kayaba monoshock with remote oil reservoir, hydraulically adjustable preload, and rebound damping adjustment. The bike has 2x 305 mm foating discs on the front brakes and single 282 mm disc on the rear brakes, with Nissin 4-piston calipers and Nissin 2-piston sliding caliper respectively, both with switchable ABS. The motorcycle measures 2248mm / 88.4in in length, 962mm / 37.9in in width (handlebars), and 1410mm / 55.5in in height without mirrors, with a wheelbase of 1435 mm / 56.5in. Its seat height ranges between 837mm / 32.9in – 857mm / 33.7in, while its wet weight is 267 kg / 586 lbs. The bike also has a fuel capacity of 20 liters / 5.3 US gal / 4.4 Imp gal, with a front tire of 110/80-19 and a rear tire of 150/70-17.

Technical specifications:

Make Model: Triumph Tiger Explorer XC

Year: 2013

Engine: Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder
Capacity: 1215 cc / 74.1 cub in
Bore x Stroke: 85 x 71.4mm
Cooling System: Liquid-cooled
Compression Ratio: 12.0:1
Induction: Multipoint sequential electronic fuel injection with SAI
Ignition: Digital
Starting: Electric
Exhaust: Stainless steel 3 into 1 , side mounted stainless steel silencer
Oil Capacity: 4.0 Litres / 1.1 US gals / 0.88 Imp gal
Max Power: 101 kW / 135 hp @ 9300rpm
Max Torque: 121 Nm / 21.6 kgf-m / 89 ft-lbs @ 6400 rpm
Clutch: Wet, multi-plate
Transmission: 6 Speed
Final Drive: Shaft

Frame: Tubular steel trellis frame, Swingarm Single-sided, cast aluminium alloy with shaft drive
Front Suspension: Kayaba 46mm upside down forks
Front Wheel Travel: 190 mm / 7.5 in
Rear Suspension: Kayaba monoshock with remote oil reservoir, hydraulically adjustable preload, rebound damping adjustment
Rear Wheel Travel: 194 mm / 7.6 in
Front Brakes: 2x 305 mm Foating discs, Nissin 4-piston calipers, switchable ABS
Rear Brakes: Single 282 mm disc, Nissin 2-piston sliding caliper, switchable ABS
Wheel Front: 32-spoke 19 x 2.5 in, aluminium rim
Wheel Rear: 32-spoke 17 x 4.0 in, aluminium rim
Front Tyre: 110/80-19
Rear Tyre: 150/70-17
Rake: 22.8 o
Trail: 90.9mm / 3.6 in
Dimensions: Length 2248mm / 88.4in Width (handlebars) 962mm 37.9in Height without mirrors 1410mm 55.5in
Wheelbase: 1435 mm / 56.5in
Seat Height: 837mm / 32.9in – 857mm/33.7in
Wet Weight: 267 kg / 586 lbs
Fuel Capacity: 20 Litres / 5.3 US gal / 4.4 Imp gal
