The TM Racing SMM 125 Black Dream is a motorcycle model released in 2006. It has a two-stroke, single-cylinder engine with a V-Force Reed valve, which has a capacity of 123.5 cc or 7.5 cu-in. The bore and stroke measure 54 x 54.5 mm, and the compression ratio is 16.7;1. It utilizes a liquid cooling system and a Keihin PWK 38 induction. The CDI electronic ignition system has a variable advance, and the bike can only be started by a kick. The motorcycle comes with a multiple-disk clutch in oil-bath with hydraulic control, a six-speed transmission, and a chain final drive.
The front suspension utilizes 46/48 Kayaba/~Ahlins USD forks while the rear suspension is an ~Ahlins mono shock. The front brakes consist of a single 320mm disc and a 4-piston caliper, while the rear brakes use a single 240mm disc and a 1-piston caliper. The front and rear tyres measure 120/70-17 and 150/70-17, respectively. The dry weight of the motorcycle is undisclosed, while the fuel capacity is 8 litres or 2.4 UA gal.
Technical specifications:
Make Model: TM Racing SMM 125 Black Dream
| Year | 2006 |
|---|---|
| Engine | Two stroke, single cylinder, V-Force Reed valve |
| Capacity | 123.5 cc / 7.5 cu-in |
| Bore x Stroke | 54 x 54,5 mm |
| Compression Ratio | 16.7;1 |
| Cooling System | Liquid cooled |
| Induction | Keihin PWK 38 |
| Ignition | CDI Electronic with variable advance |
| Starting | Kick |
| Max Power | NA |
| Max Torque | NA |
| Clutch | Multiple-disk in oil-bath with hydraulic control |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Front Suspension | 46/48 Kayaba/~Ahlins USD forks |
| Rear Suspension | ~Ahlins mono shock |
| Front Brakes | Single 320mm disc 4 piston caliper |
| Rear Brakes | Single 240mm disc 1 piston caliper |
| Front Tyre | 120/70 -17 |
| Rear Tyre | 150/70 -17 |
| Dry Weight | |
| Fuel Capacity | 8 Litres / 2.4 UA gal |
