The Sachs XTC-Racing 125 was a two-stroke, single cylinder motorcycle produced from 1998 to 2001. It featured a liquid-cooled engine with a capacity of 124.5 cc and a compression ratio of 10.7:1. The bike had a 26mm Mikuni induction system and a kick starter, producing a maximum power of 13.4 hp and maximum torque of 13 Nm. This power was transmitted through a 6-speed transmission and chain final drive. It had a hydraulic fork front suspension and monoshock rear suspension, with 120mm and 100mm wheel travel, respectively. The front and rear brakes were both equipped with two-piston calipers, with a single 316mm disc at the front and a single 220mm disc at the rear. The bike had a dry weight of 123 kg and a fuel capacity of 20 litres. The tyres were 110/70-17 at the front and 150/70-17 at the rear.
Technical specifications:
Make Model: Sachs XTC-Racing 125
| Year | 1998-01 |
|---|---|
| Engine | Two stroke, single cylinder |
| Capacity | 124.5 cc / 7.6 cu-in |
| Bore x Stroke | 41 x 47 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 10.7:1 |
| Induction | 26mm Mikuni |
| Starting | Kick |
| Max Power | 13.4 hp / 9.9 kW @ 8650 rpm |
| Max Torque | 13 Nm / 9.5 lb-ft @ 7750 rpm |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Front Suspension | Hydraulic forks, 120mm wheel travel |
| Rear Suspension | Monoshock, 100mm wheel travel. |
| Front Brakes | Single 316mm disc 2 piston caliper |
| Rear Brakes | Single 220mm disc 2 piston calipers |
| Front Tyre | 110/70-17 |
| Rear Tyre | 150/70-17 |
| Dry Weight | 123 Kg / 271 lbs |
| Fuel Capacity | 20 Litres / 5.2 US gal |
