The Polaris Slingshot and Slingshot SL are motorcycles from 2015 with a GM Ecotech, four cylinder, DOHC, VVT engine of 2384 cc/145.5 cu-in capacity, compression of 10.4:1, and liquid cooling. It requires at least 91 octane fuel and has an electric starter and 575 CCA battery. The headlights have two projector Hi/Lo H3, 44W (center) while the auxiliary lights have two projector Hi/Lo H3, 44W (outboard), and use LED. The maximum power output is 127.2 kW/173 hp @ 6200 rpm and maximum torque is 224.8 Nm/22.9 kgf-m/166 ft-lbs @ 4700 rpm. The transmission consists of 5-speed synchromesh with reverse, and the final drive is a carbon fibre reinforced belt, 36 mm x 147T. The steering is a rack and pinion system with Polaris EPAS and 3.2 steering turns (lock-to-lock). The frame is a steel space frame with ESP as well as a single sided swingarm rear suspension with ESP. The front and rear brakes are 298mm, vented, ABS, traction control, and the wheels are standard 2x Cast, 8 spokes or Sleeker 2x Cast, 10 spokes. The dimensions of the motorcycle include a length of 3800 mm/149.6 in, width of 1960 mm/77.6 in, height of 1318 mm/51.9 in, track width of 1755 mm/69.1 in, wheelbase of 2667 mm/105.0 in, ground clearance of 127 mm/5.0 in, and an adjustable seat height. Finally, the dry weight is Standard-756 kg/1666 lbs or Sleeker-764 kg/1864 lbs, and the wet weight is Standard-782 kg/1725 lbs or Sleeker-791 kg/1743 lbs. It also has a fuel capacity of 37.1 L/9.77 US gal.
Technical specifications:
Make Model: Polaris Slingshot and Slingshot SL
| Year | 2015 |
|---|---|
| Engine | GM Ecotech, four cylinder, DOHC, VVT |
| Capacity | 2384 cc / 145.5 cu-in |
| Bore x Stroke | 88 x 98 mm |
| Compression | 10.4:1 |
| Cooling System | Liquid cooled |
| Fuel | 91 octane or higher |
| Starting | Electric |
| Battery | 575 CCA |
| Headlight | 2 x Projector Hi/Lo H3, 44W (center) |
| Auxiliary Light | 2 x Projector Hi/Lo H3, 44W (outboard) |
| Other Lights | LED |
| Maximum Power | 127.2 kW / 173 hp @ 6200 rpm |
| Maximum Torque | 224.8 Nm / 22.9 kgf-m / 166 ft-lbs @4700 rpm |
| Clutch | Dry, single plate, hydraulically operated |
| Transmission | 5-Speed synchromesh with reverse |
| Final Drive | Carbon fibre reinforced belt, 36 mm x 147T |
| Gear Ratios | 1st 3.753 / 2nd 2.258 / 3rd 1.512 / 4th 1.000 / 5th 0.729:1 |
| Final Drive Ratio | 1.590:1 |
| Reverse Gear Ratio | 3.672:1 |
| Steering | Rack and pinion |
| Steering Assist | Polaris EPAS, speed sensitive |
| Steering Turns (lock-to-lock) | 3.2 |
| Frame | Steel space frame |
| Front Suspension | With ESP |
| Rear Suspension | Single sided swingarm, with ESP |
| Front Brakes | 298 mm, vented, ABS, traction control |
| Rear Brakes | 298 mm, vented, ABS, traction control |
| Wheels | Sandard: 2x Cast, 8 spokes SL: 2x Cast,10 spokes |
| Front Rim | Standard: 7 x 17 J SL: 7.5 x 18 J |
| Front Tyre | Standard: 2x 205/50 R17, Kenda 799 SL: 2x 255/45 R18, Kenda 799 |
| Rear Rim | Standard: 9.5 x 18 J SL: 9.0 x 20J |
| Rear Tyre | Standard: 265/35 R18, Kenda 799 SL: 255/45 R18, Kenda 799 |
| Dimensions | Length: 3800 mm / 149.6 in. Width: 1960 mm / 77.6 in. Height: 1318 mm / 51.9 in. |
| Track Width | 1755 mm / 69.1 in. |
| Wheelbase | 2667 mm / 105.0 in. |
| Ground Clearance | 127 mm / 5.0 in. |
| Seat Height | Adjustable |
| Dry Weight | Standard: 756 kg / 1666 lbs SL: 764 kg / 1864 lbs |
| Wet Weight | Standard: 782 kg / 1725 lbs SL: 791 kg / 1743 lbs |
| Fuel Capacity | 37.1 L / 9.77 US gal |
