The Jawa 650 Dakar is a motorbike produced in 2009 with a four-stroke single-cylinder engine, liquid cooling, and fuel injection. It has a capacity of 659cc and a maximum power of 33.8 kW at 6000 rpm. The bike features a steel tubular diamond frame and dual tank rails, with telescopic forks and a mono shock for suspension. The Jawa 650 Dakar has a 5-speed transmission, with a chain final drive, and weighs 195 kg. Its front brakes consist of 2 x ~A320 mm discs and its rear brakes are a single ~A220 mm disc. Its fuel tank has a capacity of 17 L / 4.5 US gal. With a seat height of 860 mm, the Jawa 650 Dakar is designed for off-road use, with 150mm of wheel travel on the front suspension and 170mm of wheel travel on the rear suspension. The front tire measures 100/90-19, while the rear tire is 140/80 17. Its compression ratio is 9.7:1 and its ignition is TCI. The bike is started via electric power.
Technical specifications:
Make Model: Jawa 650 Dakar
| Year | 2009 |
|---|---|
| Engine | Four stroke, single cylinder, 4 valves per cylinder. |
| Capacity | 659 cc / 40.2 cu in |
| Bore x Stroke | 100 x 84 mm |
| Compression Ratio | 9.7: 1 |
| Cooling System | Liquid cooled |
| Induction | Fuel injection, 44 mm throttle body |
| Ignition | TCI |
| Starting | Electric |
| Max Power | 33.8 kW / 48 hp @ 6000 rpm |
| Max Torque | 58.4 Nm / 5.7 kgf-m / 43.1 ft.lb @ 5250 rpm |
| Transmission | 5 Speed |
| Final Drive | Chain |
| Frame | Steel tubular diamond frame with dual tank rails |
| Front Suspension | 43 mm Telescopic forks, 150mm wheel travel |
| Front Wheel Travel | 150 mm / 5.9 in |
| Rear Suspension | Mono shock |
| Rear Wheel Travel | 170 mm / 6.7 in |
| Front Brakes | 2 x ~A320 mm discs, 2 piston caliper |
| Rear Brakes | Single ~A220 mm disc |
| Front Tyre | 100/90- 19 |
| Rear Tyre | 140/80 17 |
| Seat Height | 860 mm / 33.9 in |
| Dry Weight | 195 kg / 430 lbs |
| Fuel Capacity | 17 L / 4.5 US gal |
