The Husqvarna TE 410e is a four-stroke, single-cylinder, liquid-cooled motorcycle with a capacity of 399cc. The engine has a 11.4:1 compression ratio and is equipped with a 36mm Dell Orto carburetor and digital CDI ignition. The bike has a six-speed transmission and a final drive chain. It has a maximum power of 34 horsepower at 7000 rpm and a torque of 40.6 Nm at 5150 rpm. The front suspension is a Marzocchi 45mm inverted hydraulic fork that is adjustable for compression and rebound damping and has a front wheel travel of 285mm. The rear suspension is a Progressive Soft Damp with a single Sachs hydraulic shock absorber that is adjustable for spring preload, high- and low-speed compression damping, and rebound damping and has a rear wheel travel of 320mm. The front brakes are a single 260mm disc and the rear brakes are a single 220mm disc. The bike has a dry weight of 116kg and a fuel capacity of 9.1 litres. It has an average consumption of 19.3 km/lit and a top speed of 160.8 km/h. The bike can cover a standing quarter-mile in 13.9 seconds.
Technical specifications:
Make Model: Husqvarna TE 410e
| Year | 2000 |
|---|---|
| Engine | Four stroke, single cylinder, SOHC, 4 valve |
| Capacity | 399 cc / 24.3 cu-in |
| Bore x Stroke | 91.5 x 60.8 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 11.4:1 |
| Induction | 36mm Dell Orto carburetor |
| Ignition | Digital CDI |
| Starting | Electric & kick |
| Max Power | 34 hp / 24.8 kW @ 7000 rpm |
| Max Torque | 40.6 Nm / 30 lb-ft @ 5150 rpm |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Front Suspension | Marzocchi 45mm inverted hydraulic fork; adjustable for compression and rebound damping |
| Front Wheel Travel | 285 mm / 11.2 in |
| Rear Suspension | Progressive Soft Damp with single Sachs hydraulic shock absorber; adjustable for spring preload, high- and low- speed compression damping, and rebound damping |
| Rear Wheel Travel | 320 mm / 12.5 in |
| Front Brakes | Single 260mm disc |
| Rear Brakes | Single 220mm disc |
| Front Tyre | 90/90 -21 |
| Rear Tyre | 140/90 -18 |
| Dry Weight | 116 kg / 255.7 lbs |
| Fuel Capacity | 9.1 Litres / 2.4 US gal |
| Consumption Average | 19.3 km/lit |
| Standing 1/4 Mile | 13.9 sec |
| Top Speed | 160.8 km/h |
