The Honda CBR250R was a motorcycle model produced in 1988-89. It featured a four stroke, transverse four cylinder engine, with a 249cc capacity, and a liquid cooling system. The bike had a compression ratio of 11.5:1, and was equipped with a carburetor and CDI ignition. The motorcycle had an electric start, and was capable of producing up to 40 horsepower at 14500 rpm, and a maximum torque of 23.5 Nm at 11500 rpm. The clutch was a wet multi-plate coil spring, and the transmission was a six-speed. The bike sported Telescopic forks for its front suspension, and pro-link swing arm for its rear suspension. The brakes were hydraulic discs (two for the front, one for the rear), and the front tire had a size of 100/70-17, while the rear tire measured 130/70-17. The Honda CBR250R had a wheelbase of 1380mm (54.3in), and a seat height of 750mm (29.5in). The motorcycle weighed around 153kg (337lbs), and had a fuel capacity of 14 litres (3.6 US gal). According to Motosprint, a road test was performed on the Honda CBR250R.
Technical specifications:
Make Model: Honda CBR 250R
| Year | 1988 – 89 |
|---|---|
| Engine | Four stroke, Transverse four cylinder, DOHC, 4 valve per cylinder. |
| Capacity | 249 cc / 15.2 cu-in |
| Bore x Stroke | 48.5 x 33.8 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 11.5:1 |
| Induction | Carburetor |
| Ignition | CDI |
| Starting | Electric |
| Max Power | 40 hp / 29.2 kW @ 14500 rpm |
| Max Torque | 23.5 Nm @ 11500 rpm |
| Clutch | Wet multi-plate coil spring |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Front Suspension | Telescopic forks |
| Rear Suspension | Pro-link. swing arm |
| Front Brakes | 2x Hydraulic discs |
| Rear Brakes | Single hydraulic disc |
| Front Tyre | 100/70 -17 |
| Rear Tyre | 130/70-17 |
| Wheelbase | 1380 mm / 54.3 in |
| Seat Height | 750 mm / 29.5 in |
| Dry Weight | 153 kg / 337 lbs |
| Fuel Capacity | 14 Litres / 3.6 US gal |
| Road Test | Motosprint |
