The Honda CBR150R motorcycle was produced from 2014 to 2016. It has a four stroke, single cylinder, DOHC, 4 valve engine with a capacity of 149.4 cc. The cooling system is liquid cooled and the bike has a compression ratio of 11.0:1. The ignition is CDI and the bike is started electrically. The maximum power output is 16.9 hp at 9000 rpm and the maximum torque is 13.7 Nm at 7000 rpm. The bike has a 6-speed transmission and uses a chain for its final drive. The frame is made of aluminum and the bike has telescopic forks for its front suspension and a monoshock for its rear suspension. The front brakes consist of a single 276mm disc with a 2 piston caliper and the rear brakes consist of a single 220mm disc with a 2 piston caliper. The front and rear tires are 100/80-17 and 130/70-17, respectively. The wheelbase is 1305 mm and the seat height is 825 mm with a ground clearance of 166 mm. The dry weight of the bike is 138 kg and the fuel capacity is 13 liters.
Technical specifications:
Make Model: Honda CBR 150R
| Year | 2014 – 16 |
|---|---|
| Engine | Four stroke, single cylinder, DOHC, 4valve |
| Capacity | 149.4 cc / 9.1 cu-in |
| Cooling System | Liquid cooled |
| Bore x Stroke | 63.5 x 47.2 mm |
| Compression Ratio | 11.0: 1 |
| Induction | Injection |
| Ignition | CDI |
| Starting | Electric |
| Max Power | 16.9 hp / 12.6 kW @ 9000 rpm |
| Max Torque | 13.7 Nm / 10.1 lb-ft @ 7000 rpm |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Gear Ratio | 1st 3.038 / 2nd 1.941 / 3rd 1.500 / 4th 1.227 / 5th 1.041 / 6th 0.923 |
| Frame | Aluminum |
| Front Suspension | Telescopic forks |
| Rear Suspension | Monoshock |
| Front Brakes | Single 276mm disc 2 piston caliper |
| Rear Brakes | Single 220mm disc 2 piston caliper |
| Front Tyre | 100/80-17 |
| Rear Tyre | 130/70- 17 |
| Wheelbase | 1305 mm / |
| Seat Height | 825 mm / 32.5 in |
| Ground Clearance | 166 mm / 6.5 in |
| Dry Weight | 138 kg / 304.2 lbs |
| Fuel Capacity | 13 Litres / 3.4 US gal |
