Harley Davidson FLHXXX Street Glide Trike (2011)

The Harley Davidson FLHXXX Street Glide Trike is a motorcycle with a four-stroke V-twin engine and a 1690cc capacity. It has an air-cooled cooling system and a compression ratio of 9.7:1. The motorcycle has electronic sequential port fuel injection (ESPFI) and a single-fire, non-wasted map-controlled spark ignition. The vehicle’s maximum torque is 138 Nm / 14.1 kgf-m /102 ft/lb at 3500 rpm. It has a multi-plate, wet clutch and a 6-speed transmission with a final drive belt. The frame is made of mild steel with twin downtubes, and the front suspension is a 41.3 mm telescopic, triple-circuit damping. The vehicle has air-adjustable shocks and 2 x 300mm discs 4-piston calipers in the front and a single 300mm disc 4-piston caliper in the rear, both with ABS standard. The front tire is MT90B16 and the rear tire is 2x 205/65R15. The rake is 26 degrees and the fork angle is 32 degrees, with a trail of 100 mm / 3.9 in. The motorcycle is 2687.3 mm / 105.8 in long, 1379.2 mm / 54.3 in wide, and 1343.6 mm / 52.90 in tall, with a wheelbase of 1691 mm / 66.6 in. The seat height is laden 679.4 mm / 26.7 in unladen 721.3 mm / 28.4 in, and the ground clearance is 120 mm / 4.7 in, with a dry weight of 485.8 kg / 1071 lbs. It has a fuel capacity of 22.7 litres / 6 US gal.

Technical specifications:

Make Model: Harley Davidson FLHXXX Street Glide Trike
