The Harley Davidson FLHS 1340 Electra Glide is a motorcycle from 1988 with a four stroke, 45 degrees V-Twin, OHV, 2 valves per cylinder engine and a capacity of 1337 cc/81.7 cu-in. It is air-cooled with a bore x stroke of 88.8 x 108.0 mm and a compression ratio of 8.5:1. The bike features a 38mm Keihin carburettor and solid-state electronic ignition. It has an electric start and a maximum power of 67 hp/48.9 hp at 5000 rpm and a maximum torque of 69 lb-ft at 3000 rpm. The transmission/drive is four-speed with a final drive of the chain. The front suspension is telescopic forks with a rear suspension of dual shocks swinging arm. The front brakes are 2x 292mm discs with four-piston calipers, and the rear brakes are a single 292mm disc with a four-piston caliper. The front tyre is 90/90-16 with the rear tyre being 150/85-16. The dry weight is 343 kg/756 lbs with a fuel capacity of 19 litres/5.0 US gal.
Technical specifications:
Make Model: Harley Davidson FLHS 1340 Electra Glide
| Year | 1988 |
|---|---|
| Engine | Four stroke, 45 degrees V-Twin, OHV, 2 valves per cylinder. |
| Capacity | 1337 cc / 81.7 cu-in |
| Cooling System | Air cooled |
| Bore x Stroke | 88.8 x 108.0 mm |
| Compression Ratio | 8.5:1 |
| Induction | 38mm Keihin Carburettor |
| Ignition | Solid state electronic |
| Starting | Electric |
| Max Power | 67 hp / 48.9 hp @ 5000 rpm |
| Max Torque | 69 lb-ft @ 3000 rpm |
| Transmission / Drive | 4 Speed |
| Final Drive | Chain |
| Front Suspension | Telescopic forks |
| Rear Suspension | Dual shocks swinging arm |
| Front Brakes | 2x 292mm discs 4 piston calipers |
| Rear Brakes | Single 292mm disc 4 piston caliper |
| Front Tyre | 90/90-16 |
| Rear Tyre | 150/85-16 |
| Dry Weight | 343 kg / 756 lbs |
| Fuel Capacity | 19 Litres / 5.0 US gal |
