The Yamaha YBR 125G Dual Sport motorcycle was released in 2010 and features a four-stroke, single-cylinder, air-cooled engine with a capacity of 124cc. Its compression ratio is 10.0:1, and it has a fuel injection ignition system. It provides a maximum power of 10.1 hp at 7800 rpm and maximum torque of 10 Nm at 7400 rpm. The bike has a five-speed transmission with a final drive chain. The frame of the motorcycle is made of steel double cradle and has telescopic forks and bottom link swingarm suspension. The front brakes are single 245mm disc, and the rear brakes are drum, with 90/90-M21 tires on the front and 90/90-M18 on the rear. The rake of the bike is 26 degrees with a trail of 90mm/3.5in. The wheelbase is 1290mm/51in, with a seat height of 780mm/31.0in. It has a wet weight of 106kg/234lbs and fuel capacity of 12 litres/3.4US gal.
Technical specifications:
Make Model: Yamaha YBR 125G Dual Sport
| Year | 2010 – |
|---|---|
| Engine | Four stroke, single cylinder, SOHC, 2 valves |
| Capacity | 124 cc / 7.6 cu-in |
| Bore x Stroke | 54 x 54 mm |
| Cooling System | Air cooled |
| Compression Ratio | 10.0:1 |
| Induction | Fuel infection |
| Ignition | CDI |
| Starting | Electric |
| Max Power | 10.1 hp / 7.4 kW @ 7800 rrpm |
| Max Torque | 10 Nm @ 7400 rpm |
| Transmission | 5 Speed |
| Final Drive | Chain |
| Frame | Steel double cradle |
| Front Suspension | Telescopic forks |
| Rear Suspension | Bottom link swingarm |
| Front Brakes | Single 245mm disc |
| Rear Brakes | Drum |
| Front Tyre | 90/90-M21 |
| Rear Tyre | 90/90-M18 |
| Rake | 26 degrees |
| Trail | 90 mm / 3.5 in |
| Wheelbase | 1290 mm / 51 in |
| Seat Height | 780 mm / 31.0 in |
| Wet Weight | 106 kg / 234 lbs |
| Fuel Capacity | 12 Litres / 3.4 US gal |
