Yamaha V (2005-07)

The Yamaha XVS 1100 V-Star Classic motorcycle was produced from 2005 to 2007 and has a four-stroke, 75 degree V-twin cylinder engine with a capacity of 1063cc. The engine is air-cooled and has a compression ratio of 8.3:1. The bike has a carburetor induction and a TCI ignition system, with an electric start. It has a maximum power of 62 hp at 5750 rpm and maximum torque of 85 Nm at 2500 rpm. The transmission is a 5-speed with a shaft final drive. The front suspension is a 41mm telescopic fork with a wheel travel of 140mm, and the rear suspension is a link-type, preload-adjustable single rear shock with a wheel travel of 110mm. The front brakes are two 298mm discs with 2 piston calipers, and the rear brake is a single 282mm disc with 1 piston caliper. The front tire size is 130/90-16 and the rear is 170/80-15. The bike has a length of 2460mm, width of 945mm, and height of 1100mm, with a wheelbase of 1640mm and a seat height of 710mm. The bike’s dry weight is 272kg and wet weight is 288kg. Its fuel capacity is 17 liters or 4.4 US gallons.

Technical specifications:

Make Model: Yamaha XVS 1100 V-Star Classic

Year: 2005 – 07

Engine: Four stroke, 75 degrees V-twin cylinder SOHC, 4 valve per cylinder
Capacity: 1063 cc / 64.8 cu-in
Bore x Stroke: 95 x 75 mm
Cooling System: Air cooled
Compression Ratio: 8.3:1
Induction: Carburetors
Ignition: TCI
Starting: Electric
Max Power: 62 hp / 45.2 kW @ 5750 rpm
Max Torque: 85 Nm / 62.7 lb-ft @ 2500 rpm
Transmission: 5 Speed
Final Drive: Shaft
Front Suspension: 41mm telescopic front fork
Front Wheel Travel: 140 mm / 5.5 in
Rear Suspension: Link-type, preload-adjustable single rear shock

Rear Wheel Travel: 110 mm / 4.4 in
Front Brakes: 2x 298mm discs 2 piston calipers
Rear Brakes: Single 282mm disc 1 piston caliper
Front Tyre: 130/90-16
Rear Tyre: 170/80-15
Dimensions: Length 2460 mm / 96.9 in Width 945 mm / 37.2 in Height 1100 mm / 43.3 in
Wheelbase: 1640 mm / 64.6 in
Seat Height: 710 mm / 28 in
Dry Weight: 272 kg / 599 lbs
Wet Weight: 288kg / 634 lbs
Fuel Capacity: 17 Litres / 4.4 US gal
