The Suzuki TS 185 Sierra is a 1977 motorcycle with a two-stroke, single cylinder, aluminum, piston port engine and a capacity of 183 cc. Its compression ratio is 6.4:1 and it has a maximum power of 13.4 kW at 7000 rpm and a maximum torque of 18.6 Nm at 6500 rpm. The motorcycle has a wet, multiplate clutch and a five-speed transmission, with a final drive chain. The front suspension is a telescopic fork with oil dampening and three-way adjustability, while the rear suspension is a swinging arm with dual shocks, coil springs, oil dampening, and five-way adjustability. It has front and rear drum brakes with an internal expanding system. The front and rear tires are semi-knobbly with dimensions of 2.75-21 4PR and 3.50-18 4PR, respectively. The motorcycle has a length of 2050 mm, a width of 836 mm, and a height of 1090 mm. Its wheelbase is 1331 mm and its ground clearance is 231 mm. The Suzuki TS 185 Sierra has a claimed top speed of 121 km/h (75 mph), a climbing ability of 35 degrees, a dry weight of 101 kg, and an oil capacity of 1.2 liters and fuel capacity of 7.6 liters.
Technical specifications:
Make Model: Suzuki TS 185 Sierra
| Year | 1977 |
|---|---|
| Engine | Two stroke, single cylinder, aluminium, piston port |
| Capacity | 183 cc / 11.2 cu in |
| Bore x Stroke | 64 57 mm |
| Compression Ratio | 6.4:1 |
| Cooling System | Air cooled |
| Lubrication System | Suzuki CCI |
| Induction | Mikuni VM26 carburetor |
| Ignition | Suzuki PEI, pointless |
| Starting | Kick |
| Max Power | 13.4 kW / 18 hp @ 7000 rpm |
| Max Torque | 18.6 Nm / 1.9 kgf-m / 13.7 lb-ft @ 6500 rpm |
| Clutch | Wet, multiplate |
| Transmission | 5 Speed |
| Final Drive | Chain |
| Front Suspension | Telescopic fork, oil-dampened, 3-way adjustable |
| Front Wheel Travel | 152 mm / 6.0 in |
| Rear Suspension | Swinging arm, dual shocks, coil springs, oil-dampened, 5-way adjustable |
| Front Brakes | Drum, internal expanding |
| Rear Brakes | Drum, internal expanding |
| Front Tyre | 2.75-21 4PR Semi-knobbly |
| Rear Tyre | 3.50-18 4PR Semi-knobbly |
| Dimensions | Length: 2050 mm / 80.7 in Width: 836 mm / 32.9 in Height: 1090 mm / 42.9 in |
| Wheelbase | 1331 mm / 52.4 in |
| Ground Clearance | 231 mm / 9.1 in |
| Climbing Ability | 35o |
| Dry Weight | 101 kg / 223 lbs |
| Oil Capacity | 1.2 Litres / 2.5 US pt / 2.1 Imp pt |
| Fuel Capacity | 7.6 Litres / 2.0 US gal / 1.7 Imp gal |
| Top Speed (claimed) | 121 km/h / 75 mph |
