Suzuki

Suzuki DR-Z4S (2027)

Suzuki's 2027 DR-Z4S uses a 398 cc engine. The published engine layout is 398cc, 4-stroke, liquid-cooled, single cylinder, DOHC, with the transmission listed as 5-speed constant mesh. The listed seat height is 920 mm (36.2 in.), with a kerb/wet weight of 151 kg (333 lb.). The figures below cover the USA specification for this model year.


Technical specifications:

Make Model: Suzuki DR-Z4S

Year: 2027
Engine: 398cc, 4-stroke, liquid-cooled, single cylinder, DOHC
Bore x Stroke: 90.0 mm x 62.6 mm (3.5 in. x 2.5 in.)
Compression Ratio: 11.1:1
Induction: Fuel injection, 42 mm throttle body with 10-hole injector
Starting: Electric
Lubrication: Semi-dry sump
Clutch: Wet multi-plate, SCAS-equipped
Transmission: 5-speed constant mesh
Final Drive: Sealed O-ring type chain
Front Suspension: KYB-supplied, inverted, telescopic fork with coil spring, oil damped, and adjustable compression/rebound damping force. Travel: (280mm / 11.0 in.)
Rear Suspension: KYB-supplied, link type, coil spring, oil damped shock absorber, with adjustable spring preload and compression/rebound damping force. Travel: (296 mm / 11.6 in.)
Front Brakes: Disc brake, single 270 mm diameter stainless steel rotor
Rear Brakes: Disc brake, single 240 mm diameter stainless steel rotor
Front Tyre: 80/100-21 M/C (51P), tube type
Rear Tyre: 120/80-18 M/C (62P), tube type
Fuel Capacity: 8.7 L (2.3 US gal.)
Ignition: Electronic ignition
Headlight: Bifunction LED
Taillight: LED
Length: 2270 mm (89.4 in.)
Width: 885 mm (34.8 in.)
Height: 1230 mm (48.4 in.)
Wheelbase: 1490 mm (58.6 in.)
Ground Clearance: 300 mm (11.8 in.)
Seat Height: 920 mm (36.2 in.)
Wet Weight: 151 kg (333 lb.)
Capacity: 398 cc

Market: USA. Manufacturer specifications; equipment and units can vary by market.

Related Links: Suzuki model specifications

Photo: Suzuki. Manufacturer media.
