The Piaggio MP3 400 ie is a motorbike with a four-stroke single cylinder, SOHC, 4 valve Piaggio MASTER, catalysed 398.9cc engine. It has a compression ratio of 10.5:1 and is water-cooled with EFI fuel systems. Starting is electric and it produces 25 kW/34 hp @7500 rpm and 37 Nm/27.3 lb-ft. @5000 rpm maximum power and torque respectively. The transmission is CVT and allows for twist and go. The frame is a twin cradle, tube made of high tensile steel. The front suspension is a parallelogram composed of four aluminium arms supporting two steering tubes cantilevers with a front wheel travel of 85mm / 3.3 in, while the rear suspension has two dual-effect hydraulic shock absorbers and adjustable spring pre-load, with a rear wheel travel of 110mm / 4.3 in. The front wheel has two 240mm discs, 2 piston caliper, ABS brakes and the rear wheel has a single 240mm disc, 2 piston caliper, ABS brakes. The front tyre is 120/70-12 in, and the rear tyre is 140/70-15 in. The wheelbase is 1549mm / 61in, and the seat height is 785mm / 30.9in. The wet weight of the bike is 238 kg / 524 lbs, and it has a fuel capacity of 12 Litres / 3.2 US gal.
Make Model: Piaggio MP3 400 ie
Engine: Four stroke, single cylinder, SOHC, 4 valve Piaggio MASTER, catalysed
Capacity: 398.9 cc / 24.3 cub in.
Bore x Stroke: 69 x 85.5 mm
Compression Ratio: 10.5:1
Cooling System: Liquid cooled
Fuel System: EFI
Ignition: Electronic inductive discharge, integrated variable timing
Max Power: 25 kW / 34 hp @ 7500 rpm
Max Toque: 37 Nm / 27.3 lb-ft. @ 5000 rpm
Transmission: CVT, Twist and go
Frame: Twin cradle, tubes of high tensile steel
Front Suspension: Parallelogram composed of four aluminium arms supporting two steering tubes cantilevers
Front Wheel Travel: 85mm / 3.3 in.
Rear Suspension: Two dual effect hydraulic shock absorbers and adjustable spring pre-load
Rear Wheel Travel: 110mm / 4.3 in.
Front Brakes: 2 x 240mm discs 2 piston caliper, ABS
Rear Brakes: Single 240mm disc, 2 piston caliper, ABS
Front Tyre: 120/70-12 in.
Rear Tyre: 140/70-15 in/
Wheelbase: 1549 mm / 61 in.
Seat Height: 785 mm / 30.9 in.
Wet Weight: 238 kg / 524 lbs
Fuel Capacity: 12 Litres / 3.2 US gal
