The NSU Racemax, also known as the Blue Whale, is a 1954 motorcycle model equipped with a two-cylinder, upright shaft engine that packs a capacity of 247 cc or 15 cubic inches. The bike is air/oil cooled and operates on a dry sump lubrication system with an external oil tank and filter. It employs a twin, steel exhaust system and can reach a maximum power output of 24.3 kW or 33 horsepower at 10,500 rpm. The top speed of the NSU Racemax is 207 km/h (129 mph) and it is started via a kick start mechanism. These specifications come from the official Audi website, which is the parent company of NSU Motorenwerke AG that produced the Racemax. The Blue Whale is a rare and collectible motorcycle model with a distinctive design that features a metallic blue body with white stripes along its length, hence the name. The bike’s performance and speed have made it a notable model in the vintage motorcycle community. Overall, the NSU Racemax / Blue Whale is an iconic example of classic motorcycle engineering and a heritage that continues to influence motorcycle design in the present day.
Technical specifications:
Make Model: NSU Racemax, Blue Whale
| Year | 1954 |
|---|---|
| Engine | Two cylinder, 2 banks in-line, upright shaft engine |
| Capacity | 247 cc / 15 cub in |
| Cooling | Air/Oil cooled |
| Lubrication | Dry sump with external oil tank and filter |
| Starting | Kick start |
| Exhaust System | Twin, steel |
| Max Power | 24.3 kW / 33 hp @ 10 500 rpm |
| Top Speed | 207 km/h / 129 mph |
| Source | audi.com, |
