Kawasaki KDX200 (1999-01)

The Kawasaki KDX200 (1999-01) is a two-stroke, single cylinder, reed valve motorcycle with a capacity of 198cc. It has a liquid-cooled engine with a compression ratio of 9.4:1, and is equipped with a Keihin PWK35 carburetor and electronic CDI ignition. The bike has a maximum power output of 37hp at 8000rpm and maximum torque of 34.3Nm at 7000rpm. It has a six-speed transmission and chain final drive, with front suspension featuring 43mm telescopic forks and rear suspension consisting of a single shock with adjustable preload, 20-way compression damping, and 18-way rebound damping. The bike has a front single 250mm disc brake with a two-piston caliper and a rear single 230mm disc brake with a one-piston caliper. It has a 26.5-degree rake, 1435mm wheelbase, 919mm seat height, and 340mm ground clearance. With a dry weight of 109kg and an 11-liter fuel capacity, the Kawasaki KDX200 offers a great off-road experience.

Technical specifications:

Make Model: Kawasaki KDX 200R

Year: 1999 – 01

Engine: Two stroke, single cylinder, reed valve
Capacity: 198 cc / 12.0 cu-in
Bore x Stroke: 66 x 58 mm
Cooling System: Liquid cooled
Compression Ratio: 9.4:1
Induction: Keihin PWK35 carburetor
Ignition: Electronic CDI
Starting: Electric
Max Power: 37 hp / 27 kW @ 8000 rpm
Max Torque: 34.3 Nm / 25.2 lb-ft @ 7000 rpm
Transmission: 6 Speed
Final Drive: Chain
Front Suspension: 43mm Telescopic forks 20-way compression damping
Front Wheel Travel: 290 mm / 11.4 in
Rear Suspension: Single shock adjustable preload, 20-way compression damping and 18-way rebound damping

Rear Wheel Travel: 300 mm / 11.8 in
Front Brakes: Single 250mm disc 2 piston caliper
Rear Brakes: Single 230mm disc 1 piston caliper
Front Tyre: 80/100-21
Rear Tyre: 100/100-18
Rake: 26.5 degrees
Wheelbase: 1435 mm / 56.5 in
Seat Height: 919 mm / 36.2 in
Ground Clearance: 340 mm / 13.4 in
Dry Weight: 109 kg / 240 lbs
Fuel Capacity: 11 Litres / 2.9 US gal
