The Kawasaki KDX200 (1999-01) is a two-stroke, single cylinder, reed valve motorcycle with a capacity of 198cc. It has a liquid-cooled engine with a compression ratio of 9.4:1, and is equipped with a Keihin PWK35 carburetor and electronic CDI ignition. The bike has a maximum power output of 37hp at 8000rpm and maximum torque of 34.3Nm at 7000rpm. It has a six-speed transmission and chain final drive, with front suspension featuring 43mm telescopic forks and rear suspension consisting of a single shock with adjustable preload, 20-way compression damping, and 18-way rebound damping. The bike has a front single 250mm disc brake with a two-piston caliper and a rear single 230mm disc brake with a one-piston caliper. It has a 26.5-degree rake, 1435mm wheelbase, 919mm seat height, and 340mm ground clearance. With a dry weight of 109kg and an 11-liter fuel capacity, the Kawasaki KDX200 offers a great off-road experience.
Technical specifications:
Make Model: Kawasaki KDX 200R
| Year | 1999 – 01 |
|---|---|
| Engine | Two stroke, single cylinder, reed valve |
| Capacity | 198 cc / 12.0 cu-in |
| Bore x Stroke | 66 x 58 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 9.4:1 |
| Induction | Keihin PWK35 carburetor |
| Ignition | Electronic CDI |
| Starting | Electric |
| Max Power | 37 hp / 27 kW @ 8000 rpm |
| Max Torque | 34.3 Nm / 25.2 lb-ft @ 7000 rpm |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Front Suspension | 43mm Telescopic forks 20-way compression damping |
| Front Wheel Travel | 290 mm / 11.4 in |
| Rear Suspension | Single shock adjustable preload, 20-way compression damping and 18-way rebound damping |
| Rear Wheel Travel | 300 mm / 11.8 in |
| Front Brakes | Single 250mm disc 2 piston caliper |
| Rear Brakes | Single 230mm disc 1 piston caliper |
| Front Tyre | 80/100-21 |
| Rear Tyre | 100/100-18 |
| Rake | 26.5 degrees |
| Wheelbase | 1435 mm / 56.5 in |
| Seat Height | 919 mm / 36.2 in |
| Ground Clearance | 340 mm / 13.4 in |
| Dry Weight | 109 kg / 240 lbs |
| Fuel Capacity | 11 Litres / 2.9 US gal |
