The Indian Chieftain Dark Horse L.E. is a motorcycle with a four-stroke, V-twin engine and a capacity of 1818 cc / 111 cu in. It has a compression ratio of 9.5:1 and an electronic fuel injection system with a 54mm bore. The bike has a wet, multi-plate clutch and a 6-speed transmission with final belt drive. The frame is made of high tensile steel and features a telescopic front suspension and single shock rear suspension. The brakes consist of 2x floating rotors with 4-piston calipers at the front and a single floating rotor with 2-piston calipers at the rear. The wheels are 60 spoke 16″ x 3.5″ front and 16″ x 5″ rear. The motorcycle has a length of 2571 mm / 101.2 in, a width of 1022 mm / 40.2 in and a height of 1529 mm / 60.2 in, with a wheelbase of 1668 mm / 65.7 in. The seat height is 660 mm / 26.0 in and it has a ground clearance of 140 mm / 5.5 in. The dry weight is 370 kg / 815 lbs and wet weight is 385 kg / 848 lbs. It has a fuel capacity of 20.8 Litres / 5.5 gal.
Technical specifications:
Make Model: Indian Chieftain Dark Horse L.E.
| Year | 2016 – 17 |
|---|---|
| Engine | Four stroke, V-twin, Thunder Stroke c 111 |
| Capacity | 1818 cc / 111 cu in |
| Bore x Stroke | 101x 113 mm |
| Cooling System | Air cooled |
| Compression Ratio | 9.5:1 |
| Exhaust | System Split dual exhaust w/ cross-over |
| Induction | Electronic Fuel Injection System Closed loop fuel injection / 54mm bore |
| Starting | Electric |
| Max Toque | 1349 ft-lbs 119.2 ft-lbs / 161.6 Nm @ 3000 rpm |
| Clutch | Wet, Multi-Plate |
| Transmission | 6 Speed |
| Final Drive | Belt |
| Gear Ratio | 1st 9.403: 1 2nd 6.411: 1 3rd 4.763: 1 4th 3.796: 1 5th 3.243: 1 6th 2.789: 1 |
| Final Drive | 2.2: 1 |
| Frame | High tensile steel, monoshock |
| Front Suspension | Telescopic forks |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Suspension | Single shock |
| Rear Wheel Travel | 95 mm 3.7 in |
| Front Brakes | 2x Floating Rotor 4 piston calipers |
| Rear Brakes | Single Floating Rotor 2 piston calipers |
| Wheels | 60 Spoke 16″ x 3.5″ Front and 16″ x 5″ Rear |
| Front Tyre | 130/90B16 67H |
| Rear Tyre | 180/65B16 81H |
| Rake | 29 degrees |
| Trail | 155 mm / 6.1 in |
| Dimensions | Length 2571 mm / 101.2 in Width 1022 mm / 40.2 in Height 1529 mm / 60.2 in |
| Wheelbase | 1668 mm / 65.7 in |
| Seat Height | 660 mm / 26.0 in |
| Ground Clearance | 140 mm / 5.5 in |
| Dry Weight | 370 kg / 815 lbs |
| Wet Weight | 385 kg / 848 lbs |
| Fuel Capacity | 20.8 Litres / 5.5 gal |
