Honda

Honda CB750 Hornet (2027)

Photo: Honda

The 2027 Honda CB750 Hornet has a manufacturer-listed displacement of 755 cc. Its engine specification is liquid-cooled SOHC four-stroke eight-valve Parallel Twin with 270 degrees crank. The documented transmission is Six-speed Manual Transmission. The listed seat height is 795 mm. The figures below cover the Europe specification for this model year.

Technical specifications:

Make Model: Honda CB750 Hornet

Year: 2027
Engine: Liquid-cooled SOHC four-stroke eight-valve Parallel Twin with 270 degrees crank
Capacity: 755 cc
Bore x Stroke: 87 mm x 63.5 mm
Compression Ratio: 11.0:1
Oil Capacity: 3.8 L
Starting: E-Starter
Induction: PGM-FI Fuel Injection
Fuel Capacity: 15.2 L
Battery: 12 V 9.1 Ah (20h)
Clutch: Wet multiple, Assisted slipper clutch
Transmission: Six-speed Manual Transmission
Final Drive: Chain
Frame: Diamond Steel Frame
Dimensions: 2,090 mm x 780 mm x 1,085 mm
Wheelbase: 1,420 mm
Rake: 25 degrees
Trail: 99 mm
Seat Height: 795 mm
Ground Clearance: 140 mm
Front Suspension: Showa 41 mm SFF-BP USD, 130 mm travel
Rear Suspension: Monoshock damper, Prolink swingarm, 150 mm travel
Front Wheel: 17M/C x MT3.50 5Y-Spoke Cast Aluminium
Rear Wheel: 17M/C x MT4.50 5Y-Spoke Cast Aluminium
Front Tyre: 120/70ZR17M/C (58W)
Rear Tyre: 160/60ZR17M/C (69W)
ABS: Dual-channel ABS
Front Brakes: Radial mounted four-piston Nissin brake caliper, 296 mm floating double disc
Rear Brakes: Single piston caliper, 240 mm single disc
Headlight: LED (2-sqare projecters)
Taillight: LED
