The Hartford VR 125Z is a motorcycle with a four-stroke, single cylinder, OHV engine and 2 valves per cylinder. It has a capacity of 124 cc and a compression ratio of 9.0:1, with air cooling and a carburetor induction system. The bike has electronic starting and can reach up to 11 hp at 9000 rpm and 8.7 Nm of torque at 7000 rpm. It has a 5-speed transmission and chain final drive, with telescopic forks in the front and a single shock in the rear for suspension. The front and rear brakes both use single disc with 1 piston caliper, while the tires are 90/90-18 in the front and 110/90-18 in the rear. The bike’s measurements include a length of 2190 mm, width of 880 mm, height of 1230 mm, and a wheelbase of 1375 mm. The seat height is 810 mm, and it has a dry weight of 122.0 kg. The fuel capacity is 12 liters.
Technical specifications:
Make Model: Hartford VR 125Z
| Year | |
|---|---|
| Engine | Four stroke, single cylinder, OHV. 2 valves per cylinder |
| Capacity | 124 cc / 7.57 cu in |
| Bore x Stroke | 56.5 x 49.5 mm |
| Compression Ratio | 9.0:1 |
| Cooling System | Air cooled |
| Induction | Carburettor |
| Ignition | CDI |
| Starting | Electronic |
| Max Power | 11 hp / 8.2 kW @ 9000 rpm |
| Max Torque | 8.7 Nm / 6.4 ft. lbs @ 7000 rpm |
| Transmission | 5 Speed |
| Final Drive | Chain |
| Front Suspension | Telescopic forks |
| Rear Suspension | Single shock |
| Front Brakes | Single disc with 1 piston caliper |
| Rear Brakes | Single disc with 1 piston caliper |
| Front Tyre | 90/ 90-18 |
| Rear Tyre | 110/90 -18 |
| Dimensions | Length 2190 mm / 86.2 i Width 880 mm / 34.6 in Height 1230 mm / 48.4 in |
| Wheelbase | 1,375 mm / 54.1 inc |
| Seat Height | 810 mm / 31.9 in |
| Dry Weight | 122.0 kg / 269.0 lbs |
| Fuel Capacity | 12 Litres / 3.1 US gal |
