The CR&S Vun La Gialda (2014) motorcycle has a Rotax engine with a capacity of 652cc and a compression ratio of 9.7:1. It has an injection system, twin injectors, and twin spark ignition. The maximum power it can produce is 54 hp at 7000 rpm, and the maximum torque is 6 kgf-m at 5000 rpm. The motorcycle has a steel tube frame and a machined light alloy plate compound. The suspension is composed of a 46mm telescopic fork in the front and an oscillating swingarm with a single shock absorber in the rear. The front brake is a single 320mm disc, and the rear brake is a single 220mm disc. The motorcycle has a length of 1980mm, a width of 740mm, a wheelbase of 1386mm, and a seat height of 800mm. It has a dry weight of 135kg and a fuel capacity of 12.5 litres.
Technical specifications:
Make Model: CR&S Vun La Gialda
| Engine | Rotax, four stoke, single cylinder, DOHC, 4 valves per cylinder |
|---|---|
| Capacity | 652 cc / 39.79 cu-in |
| Bore x Stroke | 100 x 83 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 9.7;1 |
| Lubrication | Dry sump |
| Exhaust | Stainless steel catalytic exhaust system (CR and S by QD) |
| Induction | Injection. Integrated CR and S/Walbro/Dell Orto ignition/injection system, 52 mm throttle housing, twin injectors, twin spark |
| Ignition | Marelli integrated electronic, twin spark |
| Starting | Electric |
| Max Power | 54 hp / 40 kW @ 7000 rpm |
| Max Torque | 6 kgf-m / 58.9 Nm @ 5000 rpm |
| Clutch | Wet multiplate |
| Transmission | 5 Speed |
| Final Drive | With O ring chain |
| Frame | Steel tubes and machined light alloy plates compound |
| Front Suspension | 46mm Telescopic forks |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Suspension | Oscillating swingarm, single shock absorber |
| Rear Wheel Travel | 128 mm / 5.0 in |
| Front Brakes | Single 320mm disc |
| Rear Brakes | Single 220mm disc |
| Front Tyre | 120/70 ZR17 |
| Rear Tyre | 160/60 ZR-17 |
| Dimensions | Length 1980 mm / 78.0 in Width 740 mm / 29.1 in |
| Wheelbase | 1386 mm / 54.5 in |
| Seat Height | 800 mm / 31.4 in |
| Ground Clearance | 150 mm / 5.9 in |
| Dry Weight | 135 kg / 297.6 LBS |
| Fuel Capacity | 12,5 Litres / 3.3 US gal |
