Crosby Adventure (2003)

The Crosby Adventure motorcycle was made in 2003 and had a four-stroke, single-cylinder engine with a capacity of 397cc. It had a maximum power of 27 hp at 7000rpm and maximum torque of 25.8 lb-ft at 5500rpm. The bike used a wet, multi-plate clutch and a five-speed transmission with a final chain drive. The front suspension used a Fast Ace 34mm hydraulic fork that was adjustable while the rear suspension was a mono-shock design that could be adjusted for rebound compression and preload. The bike used a single 280mm disc brake in the front and a single 220mm disc brake in the rear. It also had a fuel capacity of 19 liters or 5.0 US gallons and a dry weight of 151 kg or 333 lbs. The bike was 2140mm or 84.3 inches long, 810mm or 31.9 inches wide, and 1230mm or 48.4 inches high. It had a seat height of 880mm or 34.6 inches and used Siemens EFI induction and digital electronic ignition.


Technical specifications:

Make Model: Crosby Adventure

Engine: Four Strike, Single Cylinder, SOHC, 4 Valves


Capacity: 397 cc / 24.2 cu in
Bore x Stroke:
Cooling System: Air Cooled
Induction: Siemens EFI
Ignition: Digital Electronic
Starting: Electric
Max power: 20.1 kW / 27 hp @ 7000 rpm
Max Torque: 35 Nm / 25.8 lb-ft @ 5500 rpm
Clutch: Wet, Multi Plate
Transmission: 5 Speed
Final Drive: Chain
Front Suspension: Fast Ace 34mm Hydrolic Fork, Adjustable
Rear Suspension: Mono-Shock, Adjustable Rebournd compression and preload
Front Brakes: Single 280mm disc
Rear Brakes: Single 220mm disc

Front Tyre: 90/90-21
Rear Tyre: 130/80-18
Dimensions: Length 2140mm / 84.3in Width 810mm / 31.9 in Height 1230mm / 48.4 in
Seat Height: 880mm / 34.6 in
Dry Weight: 151 kg / 333 lbs
Fuel Capacity: 19 Litres / 5.0 US gal
