The Cagiva Mito 125 is a two-stroke, single-cylinder motorcycle with a liquid-cooled engine and Dell’Orto carb induction. It has an electric variable power read valve, a 125.6cc capacity, and a compression ratio of 6.3:1. The bike has a maximum power of 34hp at 12000rpm and a maximum torque of 23Nm at 11000rpm. The clutch is wet, multiple discs, and cable-operated, while the transmission has six speeds and the final drive is a chain. The front suspension is 40mm Marzocchi telescopic forks with a front wheel travel of 120mm, while the rear suspension is progressive with a hydralyc shock and adjustable spring preload and has a rear wheel travel of 133mm. The front brakes are single 320mm discs with a four-piston caliper, and the rear brakes are single 230mm discs with a two-piston caliper. The front tire size is 110/70 ZR17, and the rear tire size is 150/60 ZR17. The motorcycle is 1100mm in height, 1980mm in length, and has a wheelbase of 1375mm. The seat height is 760mm, and the ground clearance is 150mm. It has a dry weight of 129kg and a fuel capacity of 12.5 liters or 3.0 US gallons.
Technical specifications:
Make Model: Cagiva Mito 125
| Year | 1999 – 00 |
|---|---|
| Engine | Two stroke, single cylinder, electric variable power read valve |
| Capacity | 125.6 cc / 7.6 cu-in |
| Bore x Stroke | 56 x 50.6 mm |
| Compression Ratio | 6.3:1 |
| Cooling System | Liquid cooled |
| Induction | Dell’Orto carb |
| Ignition | CDI |
| Starting | Electric |
| Max Power | 34 hp / 24.8 kW @ 12000 rpm |
| Max Torque | 23 Nm / 16.9 lb-ft @ 11000 rpm |
| Clutch | Wet, multiple discs, cable operated |
| Transmission | 6 Speed |
| Final Drive | Chain |
| Front Suspension | 40mm Marzocchi telescopic forks |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Suspension | Progressive with hydralyc shock, adjustable spring preload |
| Rear Wheel Travel | 133 mm / 5.2 in |
| Front Brakes | Single 320mm disc 4 piston caliper |
| Rear Brakes | Single 230mm disc 2 piston caliper |
| Front Tyre | 110/70 ZR17 |
| Rear Tyre | 150/60 ZR17 |
| Dimensions | Height 1100 mm / 43.3 in Length 1980 mm / 78.0 in |
| Wheelbase | 1375 mm / 54.1 in |
| Seat Height | 760 mm / 29.9 in |
| Ground Clearance | 150 mm / 5.9 in |
| Dry Weight | 129.0 kg / 284.4 lbs |
| Fuel Capacity | 12.5 Litres / 3.0 US gal |
