The Boss Hoss BHC-9 502 motorcycle has a four-stroke, V8, cast iron block engine with a capacity of 8226.8cc or 502 cubic inches. It is liquid-cooled and has a compression ratio of 9.6:1. The carburettor is a Quadrajet 850cfm, and it has an electric starting system. The maximum power is 502 horsepower or 374 kilowatts, and the maximum torque is 567 lb-ft or 768 Nm. The transmission/drive is a 2 speed semi-automatic with belt final drive. The front suspension consists of 60mm inverted forks that are preload adjustable, with 63.5mm wheel travel, while the rear suspension is dual 330mm coilover shocks that are also preload adjustable. The brakes are 2x 320mm discs with 4 piston calipers in the front and 2x 228mm drums in the rear. The front tyre size is 130/90-16, and the rear has two 275/60-15 tyres. The dry weight of the bike is 771kg or 1700lbs, and it has a fuel capacity of 32 litres or 8.5 US gallons.
Technical specifications:
Make Model: Boss Hoss BHC-9 502
| Engine | Four stroke, V8, cost iron block |
|---|---|
| Capacity | 8226.8 cc / 502 cu-in |
| Bore x Stroke | |
| Cooling System | Liquid cooled |
| Compression Ratio | 9.6:1 |
| Induction | Quadrajet 850cfm Carburettor |
| Starting | Electric |
| Max power | 502 hp / 374 kW |
| Max Torque | 567 lb-ft / 768 Nm |
| Transmission / Drive | 2 Speed semi auto |
| Final Drive | Belt |
| Front Suspension | 60mm Inverted forks preload adjustable.63.5mm wheel travel. |
| Rear Suspension | Dual 330mm coilover shocks, preload adjustable. |
| Front Brakes | 2x 320mm discs 4 piston calipers |
| Rear Brakes | 2x 228mm drum |
| Front Tyre | 130/90-16 |
| Rear Tyre | 2x 275/60-15 |
| Dry Weight | 771 kg / 1700 lbs |
| Fuel Capacity | 32 Litres / 8.5 US gal |
