The 2016 Borile B 300CR motorcycle has a four-stroke, single-cylinder, SOHC engine with a capacity of 292.4 cc. It has a compression ratio of 12:1 and is cooled by air. The lubrication system is wet sump with a trochoidal oil pump, while the exhaust is a single chrome design compliant with Euro 3 regulations. The bike uses Keihin depression in its induction system and has a digital electronic ignition that allows for effective starting. With 20 kW of power at 7500 rpm and 24 Nm of torque at 6000 rpm, the Borile B 300CR offers great performance. It uses a multi-plate clutch in oil bath, has a five-speed transmission, and uses a chain drive for final drive. The bike has a light alloy frame that is TIG welded, as well as a front hydraulic telescopic fork and single shock absorber for the rear suspension. The brakes use single discs, with a 260 mm disc at the front and a 220 mm disc at the rear, each with a two-piston caliper. The wheels are spoked and made of light alloy, with the front tyre measuring 120/70ZR17 and the rear tyre measuring 150/60ZR17. The bike is 2050 mm (80.7 in) in length, has a wheelbase of 1360 mm, a seat height of 830 mm, and a dry weight. The fuel capacity of the Borile B 300CR is not specified.
Technical specifications:
Make Model: Borile B 300CR
| Year | 2016 |
|---|---|
| Engine | Four stroke, single cylinder, SOHC, |
| Capacity | 292.4 cc / 17.8 cu-in |
| Bore x Stroke | 78 x 61.2 mm |
| Cooling System | Air cooled |
| Compression Ratio | 12:1 |
| Lubrication | Wet sump, trochoidal oil pump |
| Exhaust | Single chrome, Euro 3 |
| Induction | Keihin depression by 32. |
| Ignition | Digital electronic ignition |
| Starting | Electric |
| Max Power | 20 kW / 27.2 hp @ 7500 rpm |
| Max Torque | 24 Nm / 17.7 lb-ft @ 6000 rpm |
| Clutch | Multi-plate in oil bath |
| Transmission | 5-Speed |
| Final Drive | Chain |
| Frame | Chassis: Light alloy frame 7020 TIG welded. Sottoculla tubular steel 25CrMo4 tig welded. |
| Front Suspension | Front hydraulic telescopic fork up side down diameter stems 41, with steering plates Alu derived from full. |
| Rear Suspension | Singe shock absorber |
| Front Brakes | Single 260 mm disc, 2-piston caliper |
| Rear Brakes | Single 220 mm disc, 2-piston caliper |
| Wheels | Spoked, light alloy |
| Front Tyre | 120/70ZR17 |
| Rear Tyre | 150/60ZR17 |
| Dimensions | Length 2050 mm / 80.7 in |
| Wheelbase | 1360 mm |
| Seat Height | 830 mm |
| Dry Weight | |
| Fuel Capacity |
