Aprilia RSV 4 Factory (2009)

Entry updated

Aprilia RSV 4 Factory (2009)

At a glance

Capacity
998.9 cc / 61 cu in
Power
132 kW / 180 hp @ 12500 rpm
Torque
115 Nm / 11.7 kgf-m / 84.8 lb-ft @ 10000 rpm
Seat height
845 mm / 33.3 in

The full picture.

The Aprilia RSV-4 Factory motorcycle from 2009 boasts a four-stroke, longitudinal 65-degree V four engine with DOHC and 4 valves per cylinder, and a capacity of 998.9 cc or 61 cubic inches. Other features include variable height intake trumpets, a four-throttle body with 8 injectors, and ride-by-wire fuel management with multi-mapping. The bike also has wet sump lubrication with two oil pumps, electronic digital ignition integrated into the fuel management system, and a multi-plate wet clutch with a slipper device. The six-speed transmission has a chain drive ratio of 40/16. The double beam aluminum frame has mixed cast and pressed sheet sections with adjustments for headstock position and angle, engine height, and swingarm pivot height. The front suspension features a Ohlins A43 mm upside-down fork with adjustments for preload, compression, and rebound, while the rear suspension has a double arch aluminum swingarm with an Ohlins monoshock and APS rising rate linkages. The front brakes are lightweight stainless steel floating discs with Brembo monobloc radial calipers with four opposed pistons and sintered pads, and the rear brakes are a single disc with a Brembo floating caliper with two insulated pistons. The bike has a fuel capacity of 17 L, weighs 179 kg when dry and 205 kg when wet, and has a top speed of 289.9 km/h or 180.14 mph.


Technical specifications:

Make Model: Aprilia RSV-4 Factory

Motorcycle technical specifications
Year2009
EngineFour stroke, longitudinal 65 degrees V four , DOHC, 4 valves per cylinder
Capacity998.9 cc / 61 cu in
Bore x Stroke78 x 52.3 mm
Compression Ratio12.8:1
Cooling SystemLiquid cooled
InductionVariable height intake trumpets. Airbox with aerodynamic side intakes. 4 Throttle bodes, 8 injectors, ride-by-wire fuel management. Multi-mapping
LubricationWet sump lubrication system with oil radiator and two oil pumps (lubrication and cooling)
IgnitionElectronic digital ignition integrated in the fuel management system.
StartingElectric
Exhaust4 into 2 into 1. Lambda probe oxygen sensor. Single lateral silencer. Integrated exhaust valve and catalytic converter. (Euro 3.)
Max Power132 kW / 180 hp @ 12500 rpm
Max Torque115 Nm / 11.7 kgf-m / 84.8 lb-ft @ 10000 rpm
ClutchMulti-plate wet clutch with slipper device.
Transmission6 Speed
Final driveChain: Drive ratio: 40/16 (2,5)
Gear Ratio1st: 39:15 (2.6) / 2nd: 33:16 (2,063) / 3rd: 34:20 (1.7) / 4th: 32:22 (1,455) / 5th: 34:26 (1,308) / 6th: 33:27 (1,222)
FrameTwin beam aluminium frame with mixed cast and pressed sheet sections. Adjustments for headstock position and angle, engine height, swingarm pivot height.
Front Suspension~Ahlins ~A43 mm upside-down fork. Lower fork bottoms for radial calipers. Adjustment for preload, compression and rebound.
Front Wheel Travel120 mm / 4.7 in
Rear SuspensionDouble arch aluminium swingarm; mixed thin-wall casting and pressed sheet construction. ~Ahlins monoshock with piggy-back cylinder. Adjustments for compression, rebound, spring preload and length. APS rising rate linkages.
Rear Wheel Travel130 mm / 5.1 in
Front Brakes2 x ~A320 mm lightweight stainless steel floating discs, Brembo monobloc radial calipers with 4 opposed pistons. Sintered pads. Radial master cylinder. Metal braided brake line.
Rear BrakesSingle ~A220 mm disc. Brembo floating caliper with 2 insulated pistons. Sintered pads. Master cylinder with integral reservoir. Metal braided brake line.
Front Tyre120/70 ZR17
Rear Tyre190/55 ZR17
Steering angle24.5 degrees
Trail105 mm / 4.1 in
DimensionsLength: 2040 mm / 80.3 in Width: 735 mm / 28.9 in (at the handlebar) Height: 1120 mm / 44.1 in
Ground Clearance130 mm / 5.1 in
Seat Height845 mm / 33.3 in
Dry Weight179 Kg / 395 lbs
Wet Weight205 Kg / 453 lbs
Fuel Capacity (res)17 L / 4.5 US gal
Braking 100 – 0 km/h41,0 m / 135 ft
Standing 0 – 100 km/h3.2 sec
Standing 0 – 140 km/h4.8 sec
Standing 0 – 200 km/h7,8 sec
Standing 1/4 Mile10.6 sec
Acceleration 60-100 km/h3.7 sec
Acceleration 60-140 km/h7.3 sec
Acceleration 100-140 km/h3.6 sec
Acceleration 140-180 km/h3.8 sec
Top Speed289.9 km/h / 180.14 mph
