The AC Schnitzer HP2 is a 2007 motorcycle with a four-stroke, two-cylinder horizontally opposed boxer engine and a capacity of 1170cc/71.4cu in. It has a compression ratio of 11.0:1, an air/oil cooling system, and AC Schnitzer titanium exhaust. The fuel injection system has a 47mm throttle butterfly BMS-K, with BMS-K ignition and electric starting. It has a single plate dry clutch, 180mm, six-speed transmission, and a shaft final drive. The frame is a steel tubular space frame, non-load-bearing engine with BMW Paralever monoshock rear suspension. The front suspension is a 45mm UPSD Gabe and the front and rear brakes have 2 x 320mm discs with a 4-piston caliper and a single 265mm disc with a 2-piston caliper, respectively. The front and rear tyres are 120/70-R17 and 180/55 ZR17, respectively. It has a seat height of 920mm/36.2in, a wet weight of 190kg/419lbs and 13 Litres/3.4 US gal fuel capacity. It has an average fuel consumption of 6.0 L/100 km16.7km/l/39.2 US mpg, a standing 1/4 mile of 12.2 seconds, and a maximum speed of 210 km/h/130 mph.
Technical specifications:
Make Model: AC Schnitzer HP2
| Year | 2007 |
|---|---|
| Engine | Four stroke, two cylinder horizontally opposed Boxer, 4 Valves per cylinder |
| Capacity | 1170 cc / 71.4 cu in |
| Bore x Stroke | 101 x 73 mm |
| Compression Ratio | 11.0:1 |
| Cooling System | Air/oil cooled |
| Exhaust | AC Schnitzer Titanium exhaust system |
| Induction | Fuel Injection, 47mm throttle butterfly BMS-K |
| Ignition | BMS-K |
| Starting | Electric |
| Clutch | Single plate dry clutch, 180 mm |
| Max Power | 83 kW / 111.3 hp @ 7500rpm, |
| Max Torque | 120 Nm / 12.24 kgf-m / 88.5 lb-ft @ 5550 rpm. |
| Transmission | 6 Speed |
| Final Drive | Shaft |
| Frame | Steel tubular space frame, non-load-bearing engine |
| Front Suspension | 45mm UPSD Gabe |
| Front Wheel Travel | 305 mm / 12 in |
| Rear Suspension | BMW Paralever, monoshock |
| Rear Wheel Travel | 265 mm / 10.4 in |
| Front Brakes | 2 x 320 mm discs, 4-piston caliper |
| Rear Brakes | Single 265 mm disc, 2-piston caliper |
| Front Tyre | 120/70-R17 |
| Rear Tyre | 180/55 ZR17 |
| Seat Height | 920 mm / 36.2 in |
| Wet-Weight | 190 kg / 419 lbs |
| Fuel Capacity | 13 Litres / 3.4 US gal |
| Consumption average | 6.0 L/100 km16.7 km/l / 39.2 US mpg |
| Standing 1/4 Mile | 12.2 sec |
| Top Speed | 210 km/h / 130 mph |
