The AC Schnitzer R 1200R Roadster is a 2006 motorcycle with a four-stroke, two-cylinder horizontally opposed Boxer air/oil-cooled engine with a capacity of 1170 cc. It has a compression ratio of 12.0:1 and an electronic intake manifold injection BMS-K induction. The bike has a single disc dry clutch, hydraulically actuated and can produce a max power of 81 kW and a max torque of 120 Nm. The transmission is 6-speed with a final drive of Shaft. The bike features a tubular steel spaceframe, load-bearing engine and BMW Telelever front suspension with a front wheel travel of 120mm. The rear suspension is BMW Paralever with a rear wheel travel of 140mm. The front brakes are 2 x 320mm discs with 4-piston calipers and BMW Motorrad Integral ABS while the rear brake is a single 265mm disc with a 2-piston caliper and BMW Motorrad Integral ABS. The front tyre is 120/70-ZR 17.
Technical specifications:
Make Model: AC Schnitzer R 1200R Roadster
| Year | 2006 |
|---|---|
| Engine | Four stroke, two cylinder horizontally opposed Boxer air/oil-cooled, DOHC, rocker arm, 4 valves per cylinder |
| Capacity | 1170 cc / 71.4 cu in |
| Bore x Stroke | 101 x 73 mm |
| Compression Ratio | 12.0:1 |
| Induction | Electronic intake manifold injection BMS-K |
| Starting | Electric |
| Clutch | Single disc dry clutch, hydraulically actuated |
| Max Power | 81 kW / 110 hp @ 7750 rpm |
| Max Torque | 120 Nm 12.24 kgf-m / 88 lb/ft @ 6000 rpm |
| Transmission | 6 Speed |
| Final Drive | Shaft |
| Gear Ratio | 1st 2.375 / 2nd 1.696 / 3rd 1.296 / 4th 0.065 / 5th 0.939 / 6th 0.848 |
| Frame | Tubular steel spaceframe, load-bearing engine |
| Front Suspension | BMW Telelever |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Suspension | BMW Paralever |
| Rear Wheel Travel | 140 mm / 5.5 in |
| Front Brakes | 2 x 320 mm discs, 4-piston calipers, BMW Motorrad Integral ABS |
| Rear Brakes | Single 265 mm disc, 2-piston caliper, BMW Motorrad Integral ABS |
| Front Tyre | 120/70-ZR 17 |
